Sony STR-DA7ES - 4-2. Panel Assy; 4-3. Bracket

13
STR-DA4ES/DA7ES/VA333ES
4-2. PANEL ASSY
4-3. BRACKET
8 screw
(BV 3x8 CU)
3 screw
(BV 3x8 CU)
4 four screws
(TP), flat head
5 three screws
(TP), flat head
9 panel assy
1 CN2106
2 CN2107
6 CNP107
7 CNP111
1 screw
(BV 3x8 CU)
2 screw
(BV 3x8 CU)
3 bracket
(reinforcement(VA))
5 two screws
(BVTP 3x8
)
4 three screws
(BV 3x8 CU)
6 four screws
(BVTP 3x8)
