STR-DA4ES/DA7ES/VA333ES
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
•Abbreviation
CND : Canadian model
TW : Taiwan model
KR : Korea model
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
A-4729-679-A A-CLASS BOARD, COMPLETE (DA4ES/DA7ES)
A-4729-681-A A-CLASS BOARD, COMPLETE (VA333ES)
************************
< CAPACITOR >
C591 1-119-851-11 ELECT 22uF 20% 100V
(VA333ES)
C591 1-128-883-11 ELECT 22uF 20% 100V
(DA4ES/DA7ES)
C592 1-119-851-11 ELECT 22uF 20% 100V
(VA333ES)
C592 1-128-883-11 ELECT 22uF 20% 100V
(DA4ES/DA7ES)
C601 1-119-825-41 ELECT 22uF 20% 50V
C602 1-137-505-11 MYLAR 220PF 5% 50V
C603 1-102-233-00 CERAMIC 33PF 10% 500V
C604 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C605 1-119-779-11 ELECT 220uF 20% 10V
C610 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C611 1-126-964-11 ELECT 10uF 20% 50V
C635 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C636 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C639 1-137-503-11 MYLAR 0.0001uF 5% 50V
C650 1-119-850-11 ELECT 10uF 20% 63V
(VA333ES)
C650 1-128-868-11 ELECT 10uF 20% 63V
(DA4ES/DA7ES)
C651 1-119-825-41 ELECT 22uF 20% 50V
C652 1-137-505-11 MYLAR 220PF 5% 50V
C653 1-102-233-00 CERAMIC 33PF 10% 500V
C654 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C655 1-119-779-11 ELECT 220uF 20% 10V
C660 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C661 1-126-964-11 ELECT 10uF 20% 50V
C689 1-137-503-11 MYLAR 0.0001uF 5% 50V
C701 1-119-825-41 ELECT 22uF 20% 50V
C702 1-137-505-11 MYLAR 220PF 5% 50V
C703 1-102-233-00 CERAMIC 33PF 10% 500V
C704 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C705 1-119-779-11 ELECT 220uF 20% 10V
C710 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C711 1-126-964-11 ELECT 10uF 20% 50V
C739 1-137-503-11 MYLAR 0.0001uF 5% 50V
C750 1-119-850-11 ELECT 10uF 20% 63V
(VA333ES)
C750 1-128-868-11 ELECT 10uF 20% 63V
(DA4ES/DA7ES)
C751 1-119-825-41 ELECT 22uF 20% 50V
C752 1-137-505-11 MYLAR 220PF 5% 50V
C753 1-102-233-00 CERAMIC 33PF 10% 500V
C754 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C755 1-119-779-11 ELECT 220uF 20% 10V
C760 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C761 1-126-964-11 ELECT 10uF 20% 50V
C789 1-137-503-11 MYLAR 0.0001uF 5% 50V
< CONNECTOR >
CNP601 1-784-922-11 PIN, CONNECTOR 5P
CNP603 1-779-978-11 PIN, CONNECTOR 3P
CNP605 1-770-412-11 CONNECTOR, BOARD TO BOARD 6P
CNP607 1-770-407-11 CONNECTOR, BOARD TO BOARD 12P
CNP701 1-784-921-11 PIN, CONNECTOR 4P
< DIODE >
D611 8-719-988-61 DIODE 1SS355TE-17
D635 8-719-988-61 DIODE 1SS355TE-17
D661 8-719-988-61 DIODE 1SS355TE-17
D711 8-719-988-61 DIODE 1SS355TE-17
D761 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC601 6-700-943-01 IC uPC2581V-S
IC635 8-759-636-74 IC M5218AP-22
IC701 6-700-943-01 IC uPC2581V-S
< TRANSISTOR >
Q610 8-729-281-53 TRANSISTOR 2SC1815-GR
Q635 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q660 8-729-281-53 TRANSISTOR 2SC1815-GR
Q710 8-729-281-53 TRANSISTOR 2SC1815-GR
Q760 8-729-281-53 TRANSISTOR 2SC1815-GR
< RESISTOR >
R601 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R601 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R602 1-208-571-11 RES-CHIP 68K 2% 1/8W
(DA4ES/DA7ES)
R602 1-260-018-11 CARBON MELF 68K 2% 1/8W
(VA333ES)
R603 1-249-494-11 CARBON 68K 5% 1/2W
A-CLASS
