79
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R604 1-249-683-31 CARBON 2.7K 5% 1/2W
R609 1-216-025-11 RES-CHIP 100 5% 1/10W
R611 1-216-085-11 RES-CHIP 33K 5% 1/10W
R612 1-216-073-00 RES-CHIP 10K 5% 1/10W
R613 1-216-077-11 RES-CHIP 15K 5% 1/10W
R614 1-216-081-00 METAL CHIP 22K 5% 1/10W
R615 1-216-081-00 METAL CHIP 22K 5% 1/10W
R635 1-216-073-00 RES-CHIP 10K 5% 1/10W
R636 1-216-089-11 RES-CHIP 47K 5% 1/10W
R637 1-216-113-00 METAL CHIP 470K 5% 1/10W
R638 1-216-049-11 RES-CHIP 1K 5% 1/10W
R639 1-216-073-00 RES-CHIP 10K 5% 1/10W
R640 1-216-081-00 METAL CHIP 22K 5% 1/10W
R643 1-216-230-00 RES-CHIP 22K 2% 1/8W
(DA4ES/DA7ES)
R643 1-260-012-11 CARBON MELF 22K 2% 1/8W
(VA333ES)
R651 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R651 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R652 1-208-571-11 RES-CHIP 68K 2% 1/8W
(DA4ES/DA7ES)
R652 1-260-018-11 CARBON MELF 68K 2% 1/8W
(VA333ES)
R653 1-249-494-11 CARBON 68K 5% 1/2W
R654 1-249-683-31 CARBON 2.7K 5% 1/2W
R657 1-216-085-11 RES-CHIP 33K 5% 1/10W
R658 1-216-073-00 RES-CHIP 10K 5% 1/10W
R659 1-216-025-11 RES-CHIP 100 5% 1/10W
R667 1-216-077-11 RES-CHIP 15K 5% 1/10W
R668 1-216-081-00 METAL CHIP 22K 5% 1/10W
R669 1-216-081-00 METAL CHIP 22K 5% 1/10W
R701 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R701 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R702 1-208-571-11 RES-CHIP 68K 2% 1/8W
(DA4ES/DA7ES)
R702 1-260-018-11 CARBON MELF 68K 2% 1/8W
(VA333ES)
R703 1-249-494-11 CARBON 68K 5% 1/2W
R704 1-249-683-31 CARBON 2.7K 5% 1/2W
R709 1-216-025-11 RES-CHIP 100 5% 1/10W
R711 1-216-085-11 RES-CHIP 33K 5% 1/10W
R712 1-216-073-00 RES-CHIP 10K 5% 1/10W
R713 1-216-077-11 RES-CHIP 15K 5% 1/10W
R714 1-216-081-00 METAL CHIP 22K 5% 1/10W
R715 1-216-081-00 METAL CHIP 22K 5% 1/10W
R743 1-216-230-00 RES-CHIP 22K 2% 1/8W
(DA4ES/DA7ES)
R743 1-260-012-11 CARBON MELF 22K 2% 1/8W
(VA333ES)
R751 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R751 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R752 1-208-571-11 RES-CHIP 68K 2% 1/8W
(DA4ES/DA7ES)
R752 1-260-018-11 CARBON MELF 68K 2% 1/8W
(VA333ES)
R753 1-249-494-11 CARBON 68K 5% 1/2W
R754 1-249-683-31 CARBON 2.7K 5% 1/2W
R759 1-216-025-11 RES-CHIP 100 5% 1/10W
R761 1-216-085-11 RES-CHIP 33K 5% 1/10W
R762 1-216-073-00 RES-CHIP 10K 5% 1/10W
R763 1-216-077-11 RES-CHIP 15K 5% 1/10W
R764 1-216-081-00 METAL CHIP 22K 5% 1/10W
R765 1-216-081-00 METAL CHIP 22K 5% 1/10W
*************************************************************
A-4728-908-A AC BOARD, COMPLETE (AEP)
A-4728-949-A AC BOARD, COMPLETE (DA4ES/DA7ES)
A-4728-966-A AC BOARD, COMPLETE (KR)
A-4728-985-A AC BOARD, COMPLETE (TW)
*******************
1-533-399-31 HOLDER, FUSE
< CAPACITOR >
C901 1-113-925-11 CERAMIC 0.01uF 20% 250V
(AEP,KR)
C902 1-128-547-11 ELECT 6800uF 20% 16V
C903 1-126-943-11 ELECT 2200uF 20% 25V
C904 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C905 1-126-960-11 ELECT 1uF 20% 50V
C906 1-130-472-00 MYLAR 0.0012uF 5% 50V
(AEP,KR)
C906 1-137-432-11 MYLAR 820PF 5% 50V
(EXCEPT AEP,KR)
C907 1-137-150-11 MYLAR 0.01uF 5% 50V
(EXCEPT AEP,KR)
C907 1-137-350-11 MYLAR 0.015uF 5% 50V
(AEP,KR)
< CONNECTOR >
CNP901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P (KR)
* CNP902 1-565-792-11 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP908 1-779-978-11 PIN, CONNECTOR 3P
* CNP911 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
< AC INLET >
CNP904 1-816-148-11 INLET, AC (- AC IN) (EXCEPT KR)
< DIODE >
D901 8-719-085-36 DIODE 11EQS04-TB5
D902 8-719-085-36 DIODE 11EQS04-TB5
D903 8-719-085-36 DIODE 11EQS04-TB5
D904 8-719-085-36 DIODE 11EQS04-TB5
D905 8-719-988-61 DIODE 1SS355TE-17
D906 8-719-988-61 DIODE 1SS355TE-17
D907 8-719-988-61 DIODE 1SS355TE-17
D908 8-719-053-18 DIODE 1SR154-400TE-25
< TERMINAL >
* EP901 1-537-738-21 TERMINAL, EARTH
< AC OUTLET >
0 J901 1-251-718-11 OUTLET (2 GANG), AC (AC OUTLET)
(EXCEPT AEP,KR)
0 J901 1-785-285-11 OUTLET, AC (1P) (AC OUTLET) (AEP)
A-CLASS
AC
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
