Sony STR-DA7ES - AMP Board Components

80
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< TRANSISTOR >
Q901 8-729-230-49 TRANSISTOR 2SC2712-YG
Q902 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q903 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q904 8-729-140-93 TRANSISTOR 2SB733-34
< RESISTOR >
0 R901 1-219-237-11 SOLID 3.3M 20% 1/2W F
(DA4ES/DA7ES)
R902 1-216-073-00 RES-CHIP 10K 5% 1/10W
R903 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R904 1-216-093-11 RES-CHIP 68K 5% 1/10W
R905 1-216-085-11 RES-CHIP 33K 5% 1/10W
R906 1-216-049-11 RES-CHIP 1K 5% 1/10W
(AEP)
R906 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
(EXCEPT AEP,KR)
R907 1-216-097-11 RES-CHIP 100K 5% 1/10W
R908 1-216-073-00 RES-CHIP 10K 5% 1/10W
R909 1-216-085-11 RES-CHIP 33K 5% 1/10W
R910 1-216-073-00 RES-CHIP 10K 5% 1/10W
< RELAY >
0 RY901 1-755-388-11 RELAY (AC POWER) (DA4ES/DA7ES)
0 RY901 1-755-393-11 RELAY, POWER (VA333ES)
< TRANSFORMER >
0 T902 1-435-162-21 TRANSFORMER, POWER (DA4ES/DA7ES)
0 T902 1-435-163-21 TRANSFORMER, POWER (AEP,KR)
0 T902 1-437-477-12 TRANSFORMER, POWER (TW)
*************************************************************
A-4728-907-A AMP BOARD, COMPLETE (VA333ES)
A-4728-947-A AMP BOARD, COMPLETE (DA4ES/DA7ES)
*********************
< CAPACITOR >
C500 1-119-850-11 ELECT 10uF 20% 63V
(VA333ES)
C500 1-128-868-11 ELECT 10uF 20% 63V
(DA4ES/DA7ES)
C501 1-119-825-41 ELECT 22uF 20% 50V
C502 1-137-505-11 MYLAR 220PF 5% 50V
C503 1-102-233-00 CERAMIC 33PF 10% 500V
C504 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C505 1-119-779-11 ELECT 220uF 20% 10V
C507 1-128-879-11 ELECT 2.2uF 20% 100V
C520 1-119-827-11 ELECT 47uF 20% 50V
(VA333ES)
C520 1-128-860-11 ELECT 47uF 20% 50V
(DA4ES/DA7ES)
C523 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C524 1-137-372-11 MYLAR 0.022uF 5% 50V
C539 1-137-503-11 MYLAR 0.0001uF 5% 50V
C541 1-128-858-11 ELECT 22uF 20% 50V
C542 1-128-834-11 ELECT 470uF 20% 10V
C551 1-119-825-41 ELECT 22uF 20% 50V
C552 1-137-505-11 MYLAR 220PF 5% 50V
C553 1-102-233-00 CERAMIC 33PF 10% 500V
C554 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C555 1-119-779-11 ELECT 220uF 20% 10V
C570 1-119-827-11 ELECT 47uF 20% 50V
(VA333ES)
C570 1-128-860-11 ELECT 47uF 20% 50V
(DA4ES/DA7ES)
C573 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C574 1-137-372-11 MYLAR 0.022uF 5% 50V
C589 1-137-503-11 MYLAR 0.0001uF 5% 50V
C593 1-126-077-11 ELECT 100uF 20% 100V
C594 1-126-077-11 ELECT 100uF 20% 100V
C595 1-128-883-11 ELECT 22uF 20% 100V
C596 1-128-883-11 ELECT 22uF 20% 100V
C597 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C600 1-119-850-11 ELECT 10uF 20% 63V
(VA333ES)
C600 1-128-868-11 ELECT 10uF 20% 63V
(DA4ES/DA7ES)
C608 1-130-777-00 MYLAR 0.1uF 10% 100V
C609 1-130-777-00 MYLAR 0.1uF 10% 100V
C620 1-119-827-11 ELECT 47uF 20% 50V
(VA333ES)
C620 1-128-860-11 ELECT 47uF 20% 50V
(DA4ES/DA7ES)
C623 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C624 1-137-372-11 MYLAR 0.022uF 5% 50V
C670 1-119-827-11 ELECT 47uF 20% 50V
(VA333ES)
C670 1-128-860-11 ELECT 47uF 20% 50V
(DA4ES/DA7ES)
C673 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C674 1-137-372-11 MYLAR 0.022uF 5% 50V
C681 1-119-825-41 ELECT 22uF 20% 50V
C682 1-137-505-11 MYLAR 220PF 5% 50V
C683 1-119-779-11 ELECT 220uF 20% 10V
C684 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C685 1-102-233-00 CERAMIC 33PF 10% 500V
C687 1-137-503-11 MYLAR 0.0001uF 5% 50V
C691 1-119-827-11 ELECT 47uF 20% 50V
(VA333ES)
C691 1-128-860-11 ELECT 47uF 20% 50V
(DA4ES/DA7ES)
C692 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C693 1-137-372-11 MYLAR 0.022uF 5% 50V
C720 1-119-827-11 ELECT 47uF 20% 50V
(VA333ES)
C720 1-128-860-11 ELECT 47uF 20% 50V
(DA4ES/DA7ES)
C723 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C724 1-137-372-11 MYLAR 0.022uF 5% 50V
C770 1-119-827-11 ELECT 47uF 20% 50V
(VA333ES)
C770 1-128-860-11 ELECT 47uF 20% 50V
(DA4ES/DA7ES)
C773 1-163-125-00 CERAMIC CHIP 220PF 5% 50V
C774 1-137-372-11 MYLAR 0.022uF 5% 50V
< CONNECTOR >
CN504 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CNP501 1-779-977-11 PIN, CONNECTOR 6P
AMPAC
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
