Sony STR-DA7ES - Page 81

81
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
CNP503 1-785-104-11 PIN, CONNECTOR (3.96mm PITCH) 6P
CNP504 1-784-923-11 PIN, CONNECTOR 7P
CNP505 1-785-102-21 PIN, CONNECTOR (3.96mm PITCH) 4P
CNP509 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CNP602 1-779-978-21 PIN, CONNECTOR 3P
CNP606 1-770-379-11 CONNECTOR, BOARD TO BOARD 6P
CNP608 1-770-382-11 CONNECTOR, BOARD TO BOARD 12P
CNP702 1-785-103-11 PIN, CONNECTOR (3.96mm PITCH) 5P
< DIODE >
D501 8-719-988-61 DIODE 1SS355TE-17
D502 8-719-036-66 DIODE RD2.2SB-T1
D503 8-719-036-66 DIODE RD2.2SB-T1
D504 8-719-988-61 DIODE 1SS355TE-17
D505 8-719-988-61 DIODE 1SS355TE-17
D547 8-719-988-61 DIODE 1SS355TE-17
D548 8-719-988-61 DIODE 1SS355TE-17
D549 8-719-988-61 DIODE 1SS355TE-17
D551 8-719-988-61 DIODE 1SS355TE-17
D552 8-719-036-66 DIODE RD2.2SB-T1
D553 8-719-036-66 DIODE RD2.2SB-T1
D554 8-719-988-61 DIODE 1SS355TE-17
D555 8-719-988-61 DIODE 1SS355TE-17
D591 8-719-083-61 DIODE UDZS-TE-17-11B (US, CND)
D591 8-719-083-63 DIODE UDZS-TE-17-13B (EXCEPT US, CND)
D592 8-719-083-82 DIODE UDZS-TE-17-12B (EXCEPT US, CND)
D592 8-719-977-28 DIODE UDZS-TE-17-10B (US, CND)
D593 8-719-988-61 DIODE 1SS355TE-17
D594 8-719-988-61 DIODE 1SS355TE-17
D599 8-719-988-61 DIODE 1SS355TE-17
D601 8-719-988-61 DIODE 1SS355TE-17
D602 8-719-036-66 DIODE RD2.2SB-T1
D603 8-719-036-66 DIODE RD2.2SB-T1
D604 8-719-988-61 DIODE 1SS355TE-17
D605 8-719-988-61 DIODE 1SS355TE-17
D651 8-719-988-61 DIODE 1SS355TE-17
D652 8-719-036-66 DIODE RD2.2SB-T1
D653 8-719-036-66 DIODE RD2.2SB-T1
D654 8-719-988-61 DIODE 1SS355TE-17
D655 8-719-988-61 DIODE 1SS355TE-17
D671 8-719-988-61 DIODE 1SS355TE-17
D672 8-719-036-66 DIODE RD2.2SB-T1
D673 8-719-036-66 DIODE RD2.2SB-T1
D674 8-719-988-61 DIODE 1SS355TE-17
D675 8-719-988-61 DIODE 1SS355TE-17
D701 8-719-988-61 DIODE 1SS355TE-17
D702 8-719-036-66 DIODE RD2.2SB-T1
D703 8-719-036-66 DIODE RD2.2SB-T1
D704 8-719-988-61 DIODE 1SS355TE-17
D705 8-719-988-61 DIODE 1SS355TE-17
D751 8-719-988-61 DIODE 1SS355TE-17
D752 8-719-036-66 DIODE RD2.2SB-T1
D753 8-719-036-66 DIODE RD2.2SB-T1
D754 8-719-988-61 DIODE 1SS355TE-17
D755 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC501 6-700-943-01 IC uPC2581V-S
IC651 6-700-943-01 IC uPC2581V-S
< TRANSISTOR >
Q501 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q503 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q508 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q509 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q547 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q548 8-729-230-49 TRANSISTOR 2SC2712-YG
Q549 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q558 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q559 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q591 8-729-021-82 TRANSISTOR 2SD2396K
Q592 8-729-024-93 TRANSISTOR 2SB1565E
Q593 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q599 8-729-230-49 TRANSISTOR 2SC2712-YG
Q608 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q609 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q651 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q652 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q658 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q659 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q708 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q709 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q758 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q759 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
< RESISTOR >
R501 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R501 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R502 1-208-571-11 RES-CHIP 68K 2% 1/8W
(DA4ES/DA7ES)
R502 1-260-018-11 CARBON MELF 68K 2% 1/8W
(VA333ES)
R503 1-249-494-11 CARBON 68K 5% 1/2W
R504 1-249-683-31 CARBON 2.7K 5% 1/2W
R505 1-216-089-11 RES-CHIP 47K 5% 1/10W
R509 1-216-025-11 RES-CHIP 100 5% 1/10W
R510 1-215-868-00 METAL OXIDE 680 5% 1W
R521 1-216-055-00 METAL CHIP 1.8K 5% 1/10W
R522 1-216-077-11 RES-CHIP 15K 5% 1/10W
R523 1-216-093-11 RES-CHIP 68K 5% 1/10W
R524 1-249-393-11 CARBON 10 5% 1/4W
R525 1-249-393-11 CARBON 10 5% 1/4W
R526 1-208-401-11 RES-CHIP 33 2% 1/8W
(DA4ES/DA7ES)
R526 1-259-977-11 CARBON MELF 33 2% 1/8W
(VA333ES)
R527 1-240-855-11 CARBON 6.2K 5% 1/4W
R528 1-216-214-00 RES-CHIP 4.7K 2% 1/8W
(DA4ES/DA7ES)
R528 1-260-004-11 CARBON MELF 4.7K 2% 1/8W
(VA333ES)
R529 1-216-089-11 RES-CHIP 47K 5% 1/10W
R530 1-249-393-11 CARBON 10 5% 1/4W
R539 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R540 1-216-049-11 RES-CHIP 1K 5% 1/10W
R541 1-216-689-11 METAL CHIP 39K 0.5% 1/10W
R542 1-216-073-00 RES-CHIP 10K 5% 1/10W
AMP
