106
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C382 1-137-505-11 MYLAR 220PF 5% 50V
(DA4ES/DA7ES)
C383 1-128-858-11 ELECT 22uF 20% 50V
(DA4ES/DA7ES)
C384 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
(DA4ES/DA7ES)
C385 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
(DA4ES/DA7ES)
C391 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
(DA7ES)
C392 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
(DA7ES)
C393 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(DA7ES)
C394 1-136-169-00 MYLAR 0.22uF 5% 50V
C395 1-136-169-00 MYLAR 0.22uF 5% 50V
C396 1-119-805-21 ELECT 2200uF 20% 25V
(VA333ES)
C396 1-127-728-51 ELECT 2200uF 20% 25V
(DA4ES/DA7ES)
C397 1-119-805-21 ELECT 2200uF 20% 25V
(VA333ES)
C397 1-127-728-51 ELECT 2200uF 20% 25V
(DA4ES/DA7ES)
C398 1-163-038-00 CERAMIC CHIP 0.1uF 25V
(DA7ES)
C399 1-119-803-11 ELECT 470uF 20% 25V
(VA333ES)
C399 1-127-726-11 ELECT 470uF 20% 25V
(DA4ES/DA7ES)
< CONNECTOR >
CN301 1-784-921-11 PIN, CONNECTOR 4P
CNP302 1-784-921-11 PIN, CONNECTOR 4P
CNP303 1-784-923-11 PIN, CONNECTOR 7P
CNP304 1-784-928-11 PIN, CONNECTOR 13P
CNP305 1-779-978-11 PIN, CONNECTOR 3P
CNP306 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
* CNP307 1-564-707-11 PIN, CONNECTOR (SMALL TYPE) 5P
< DIODE >
D301 8-719-988-61 DIODE 1SS355TE-17 (DA4ES/DA7ES)
< TERMINAL >
* EPT301 1-537-738-21 TERMINAL, EARTH
< IC >
IC301 8-759-711-85 IC NJM4580E-D
IC302 8-759-835-78 IC TC9274N-015
IC303 8-759-835-78 IC TC9274N-015
IC304 8-759-582-66 IC TC9273N-013 (DA7ES)
IC305 8-759-710-59 IC NJM4580D-D (DA4ES/DA7ES)
IC306 8-759-711-85 IC NJM4580E-D
IC307 8-759-711-85 IC NJM4580E-D (DA7ES)
IC308 8-759-231-59 IC TA7815S
IC309 8-759-245-87 IC TA79015S
IC310 8-759-231-58 IC TA7812S
IC311 8-759-835-76 IC TC94A07P (DA4ES/DA7ES)
IC312 8-759-231-59 IC TA7815S
IC313 8-759-245-87 IC TA79015S
IC314 8-759-711-85 IC NJM4580E-D (DA4ES/DA7ES)
< JACK >
J301 1-778-517-11 JACK, PIN 6P (PHONO,CD/SACD,MD/DAT OUT)
J302 1-778-517-11 JACK, PIN 6P (MD/DAT IN,TAPE)
J303 1-784-934-11 JACK, PIN 4P (TV/SAT,DVD/LD)
J304 1-784-934-11 JACK, PIN 4P (VIDEO 2)
J305 1-778-517-11 JACK, PIN 6P (VIDEO 1,2ND ROOM)
(DA4ES/DA7ES)
J305 1-784-934-11 JACK, PIN 4P (VIDEO 1) (VA333ES)
< TRANSISTOR >
Q301 8-729-230-49 TRANSISTOR 2SC2712-YG (DA4ES/DA7ES)
< RESISTOR >
R301 1-208-453-41 RES-CHIP 4.7K 2% 1/10W
R302 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R303 1-216-697-11 METAL CHIP 82K 0.5% 1/10W
R304 1-216-633-11 METAL CHIP 180 0.5% 1/10W
R305 1-216-673-11 METAL CHIP 8.2K 0.5% 1/10W
R306 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R307 1-216-627-11 METAL CHIP 100 0.5% 1/10W
R308 1-216-699-11 METAL CHIP 100K 0.5% 1/10W
R309 1-208-774-11 RES-CHIP 470 2% 1/10W
R310 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R310 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R311 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R311 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R312 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R312 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R313 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R313 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R314 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R314 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R315 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R315 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R316 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
R316 1-259-995-11 CARBON MELF 1K 2% 1/8W
(VA333ES)
R317 1-216-206-00 RES-CHIP 2.2K 2% 1/8W
(DA4ES/DA7ES)
R317 1-259-999-11 CARBON MELF 2.2K 2% 1/8W
(VA333ES)
R318 1-208-782-11 RES-CHIP 1K 2% 1/8W
(DA4ES/DA7ES)
INPUT
