97
STR-DA4ES/DA7ES/VA333ES
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R118 1-216-001-00 METAL CHIP 10 5% 1/10W
R119 1-249-385-11 CARBON 2.2 5% 1/6W
R120 1-249-385-11 CARBON 2.2 5% 1/6W
R121 1-216-037-00 METAL CHIP 330 5% 1/10W
R122 1-216-037-00 METAL CHIP 330 5% 1/10W
R123 1-216-089-11 RES-CHIP 47K 5% 1/10W
R124 1-216-049-11 RES-CHIP 1K 5% 1/10W
R125 1-216-049-11 RES-CHIP 1K 5% 1/10W
R126 1-216-037-00 METAL CHIP 330 5% 1/10W
R127 1-216-029-00 METAL CHIP 150 5% 1/10W
R128 1-216-029-00 METAL CHIP 150 5% 1/10W
R129 1-216-037-00 METAL CHIP 330 5% 1/10W
R131 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R132 1-216-298-00 METAL CHIP 2.2 5% 1/10W
R133 1-216-073-00 RES-CHIP 10K 5% 1/10W
R134 1-216-073-00 RES-CHIP 10K 5% 1/10W
R135 1-216-089-11 RES-CHIP 47K 5% 1/10W
R136 1-216-089-11 RES-CHIP 47K 5% 1/10W
R137 1-216-089-11 RES-CHIP 47K 5% 1/10W
R138 1-216-081-00 METAL CHIP 22K 5% 1/10W
R139 1-216-073-00 RES-CHIP 10K 5% 1/10W
R140 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R141 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R142 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R143 1-216-049-11 RES-CHIP 1K 5% 1/10W
R144 1-216-073-00 RES-CHIP 10K 5% 1/10W
R145 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R146 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R147 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R148 1-216-049-11 RES-CHIP 1K 5% 1/10W
R149 1-216-089-11 RES-CHIP 47K 5% 1/10W
R150 1-216-081-00 METAL CHIP 22K 5% 1/10W
R151 1-216-073-00 RES-CHIP 10K 5% 1/10W
R152 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R153 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R154 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R155 1-216-049-11 RES-CHIP 1K 5% 1/10W
R156 1-216-089-11 RES-CHIP 47K 5% 1/10W
R157 1-216-081-00 METAL CHIP 22K 5% 1/10W
R158 1-216-073-00 RES-CHIP 10K 5% 1/10W
R159 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R160 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R161 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R162 1-216-049-11 RES-CHIP 1K 5% 1/10W
R163 1-216-073-00 RES-CHIP 10K 5% 1/10W
R175 1-216-073-00 RES-CHIP 10K 5% 1/10W
R176 1-216-073-00 RES-CHIP 10K 5% 1/10W
< ROTARY ENCODER >
RV102 1-418-921-11 ENCODER, ROTARY (JOG DIAL)
< SWITCH >
S101 1-771-349-21 SWITCH, KEYBOARD (POWER)
S102 1-771-349-21 SWITCH, KEYBOARD (DISPLAY)
S103 1-771-349-21 SWITCH, KEYBOARD (DIMMER)
S104 1-771-349-21 SWITCH, KEYBOARD (CINEMA STUDIO EX)
S105 1-771-349-21 SWITCH, KEYBOARD (FM/AM)
S106 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING –)
S107 1-771-349-21 SWITCH, KEYBOARD (PRESET TUNING +)
S108 1-771-349-21 SWITCH, KEYBOARD (AUTO DEC)
S109 1-771-349-21 SWITCH, KEYBOARD (MODE –)
S110 1-771-349-21 SWITCH, KEYBOARD (MODE +)
S111 1-771-349-21 SWITCH, KEYBOARD (2CH STEREO)
S112 1-771-349-21 SWITCH, KEYBOARD (ANALOG DIRECT)
S113 1-771-349-21 SWITCH, KEYBOARD (MULTI CH DIRECT)
S114 1-771-349-21 SWITCH, KEYBOARD (DOLBY PL II/NEO:6)
S115 1-771-349-21 SWITCH, KEYBOARD (SURR BACK DECODING)
S116 1-771-349-21 SWITCH, KEYBOARD (TUNING –)
S117 1-771-349-21 SWITCH, KEYBOARD (TUNING +)
S118 1-771-349-21 SWITCH, KEYBOARD (2ND/3RD ROOM)
S119 1-771-349-21 SWITCH, KEYBOARD (ON SCREEN)
S120 1-771-349-21 SWITCH, KEYBOARD (SURROUND)
S121 1-771-349-21 SWITCH, KEYBOARD (LEVEL)
S122 1-771-349-21 SWITCH, KEYBOARD (JOG <)
S123 1-771-349-21 SWITCH, KEYBOARD (JOG >)
S124 1-771-349-21 SWITCH, KEYBOARD (FM MODE)
S125 1-771-349-21 SWITCH, KEYBOARD (MEMORY)
S126 1-771-349-21 SWITCH, KEYBOARD (NIGHT MODE)
S127 1-771-349-21 SWITCH, KEYBOARD (EQ BANK)
S128 1-771-349-21 SWITCH, KEYBOARD (CUSTOMIZE)
S129 1-771-349-21 SWITCH, KEYBOARD (EQ)
S130 1-771-349-21 SWITCH, KEYBOARD (ENTER)
S131 1-771-349-21 SWITCH, KEYBOARD (SET UP)
< SWITCH >
SW101 1-762-268-11 SWITCH, ROTARY (SPEAKERS)
*************************************************************
A-4728-878-A E-VOL BOARD, COMPLETE (DA4ES)
A-4728-891-A E-VOL BOARD, COMPLETE (VA333ES)
A-4728-911-A E-VOL BOARD, COMPLETE (DA7ES)
**********************
< CAPACITOR >
C401 1-119-825-41 ELECT 22uF 20% 50V
(VA333ES)
C401 1-128-858-11 ELECT 22uF 20% 50V
(DA4ES/DA7ES)
C402 1-119-825-41 ELECT 22uF 20% 50V
(VA333ES)
C402 1-128-858-11 ELECT 22uF 20% 50V
(DA4ES/DA7ES)
C403 1-119-779-11 ELECT 220uF 20% 10V
(VA333ES)
C403 1-128-832-11 ELECT 220uF 20% 10V
(DA4ES/DA7ES)
C404 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA333ES)
C405 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA333ES)
C406 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA333ES)
C407 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA333ES)
C408 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
(VA333ES)
DISPLAY E-VOL
