SERVICE MANUAL
Ver. 1.5 2006.11
9-877-370-81
STR-DA1000ES/DB790
US Model
Canadian Model
STR-DA1000ES
AEP Model
UK Model
E Model
Australian Model
Chinese Model
STR-DB790
SUPPLEMENT-1
File this supplement with the service manual.
In this set, MAIN board has been changed in the midway of production.
Moreover, specified value for bias adjustment has been changed at the same
time as changing MAIN board.
Only new MAIN board and bias adjustment corresponding to new MAIN board
have been described.
Refer to original service manual for other information.
Subject:Change of MAIN board (Suffix-15)
Change of specified value for bias adjustment according
to change in MAIN board
1. NEW/FORMER DISCRIMINATION
– MAIN Board (Component Side) –
Position of silk
Perform after confirming which type set of the repair referring to the following.
Printed on Silk Remark
Former type 1-688-629-11, -12 Refer to original service manual
New type 1-688-629-13, -14, -15 Refer to service manual supplement-1
Note 1:In original service manual, only suffix-11 has been described.
Note 2:In service manual supplement-1, only suffix-15 has been described.
