79
STR-DA1000ES/DB790
SECTION 8
ELECTRICAL PARTS LIST
4/8 SW A-CLASS
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
4/8 SW BOARD
************
< CONNECTOR >
* CN901 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
CN902 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
< SWITCH >
S901 1-771-876-11 SWITCH, POWER (IMPEDANCE SELECTOR)
**************************************************************
A-4733-467-A A-CLASS BOARD, COMPLETE
(DB790: AEP, UK, AUS)
A-4733-513-A A-CLASS BOARD, COMPLETE (DA1000ES)
A-4733-539-A A-CLASS BOARD, COMPLETE
(DB790: SP, MY, TW, KR, CH)
************************
< CAPACITOR >
C2001 1-137-505-11 FILM 220PF 5% 100V
C2002 1-128-551-11 ELECT 22uF 20% 63V
(DA1000ES)
C2002 1-128-869-11 ELECT 22uF 20% 63V
(DB790: SP, MY, TW, KR, CH)
C2002 1-135-768-11 ELECT 22uF 63V
(DB790: AEP, UK, AUS)
C2004 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C2004 1-127-719-11 ELECT 220uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C2004 1-135-710-11 ELECT 220uF 16V
(DB790: AEP, UK, AUS)
C2005 1-126-940-11 ELECT 330uF 20% 25V
(DA1000ES)
C2005 1-128-846-11 ELECT 330uF 20% 25V
(DB790: SP, MY, TW, KR, CH)
C2005 1-135-683-11 ELECT 330uF 25V
(DB790: AEP, UK, AUS)
C2006 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2007 1-102-233-00 CERAMIC 33PF 10% 500V
C2008 1-137-383-11 MYLAR 220PF 5% 100V
C2009 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2010 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2101 1-137-505-11 FILM 220PF 5% 100V
C2102 1-128-551-11 ELECT 22uF 20% 63V
(DA1000ES)
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C2102 1-128-869-11 ELECT 22uF 20% 63V
(DB790: SP, MY, TW, KR, CH)
C2102 1-135-768-11 ELECT 22uF 63V
(DB790: AEP, UK, AUS)
C2104 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C2104 1-127-719-11 ELECT 220uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C2104 1-135-710-11 ELECT 220uF 16V
(DB790: AEP, UK, AUS)
C2105 1-126-940-11 ELECT 330uF 20% 25V
(DA1000ES)
C2105 1-128-846-11 ELECT 330uF 20% 25V
(DB790: SP, MY, TW, KR, CH)
C2105 1-135-683-11 ELECT 330uF 25V
(DB790: AEP, UK, AUS)
C2106 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2107 1-102-233-00 CERAMIC 33PF 10% 500V
C2108 1-137-383-11 MYLAR 220PF 5% 100V
C2109 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2110 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2201 1-137-505-11 FILM 220PF 5% 100V
C2202 1-128-551-11 ELECT 22uF 20% 63V
(DA1000ES)
C2202 1-128-869-11 ELECT 22uF 20% 63V
(DB790: SP, MY, TW, KR, CH)
C2202 1-135-768-11 ELECT 22uF 63V
(DB790: AEP, UK, AUS)
C2204 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C2204 1-127-719-11 ELECT 220uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C2204 1-135-710-11 ELECT 220uF 16V
(DB790: AEP, UK, AUS)
C2205 1-126-940-11 ELECT 330uF 20% 25V
(DA1000ES)
C2205 1-128-846-11 ELECT 330uF 20% 25V
(DB790: SP, MY, TW, KR, CH)
C2205 1-135-683-11 ELECT 330uF 25V
(DB790: AEP, UK, AUS)
C2206 1-102-230-00 CERAMIC 4PF 0.25PF 500V
C2207 1-102-233-00 CERAMIC 33PF 10% 500V
C2208 1-137-383-11 MYLAR 220PF 5% 100V
C2209 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2210 1-137-389-11 MYLAR 0.0022uF 5% 100V
C2301 1-137-505-11 FILM 220PF 5% 100V
•Abbreviation
AUS: Australian model
CND : Canadian model
CH : Chinese model
KR : Korean model
MY : Malaysia model
SP : Singapore model
TW : Taiwan model
When indicating parts by reference
number, please include the board.
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Ver 1.1
