Sony STR-DB790 Service Manual

13
STR-DA1000ES/DB790
3-6. DIGITAL BOARD
3-7. STAY3/STAY4/SP-B/SP-A/S-VIDEO/VIDEO/VIDEO-AU/AU-IN BOARD
3 connector
(CN1107)
1 connector (CN1110)
2 connector (CN1106)
5 digital boar
d
4 two connectors
(CN402, 403)
8 SP-B board
0 SP-A board
6 STAY4 board
3 STAY3 board
qs S-video board
5 connector (CN451)
4 connector (CN450)
7 two connectors (CN412, 413)
9 two connectors (CN410, 411)
qa connector (CN408)
qg connector (CN406)
ql AU-IN board
qh video-AU board
qj harness (CN132)
qk connector (CN404, 405)
2 connector (CN447)
1 connector (CN104)
qd connector (CN407)
qf video board
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL 13942296513 QQ 376315150 892498299 TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

Sony STR-DB790 Specifications

General

Dimensions (WxDxH)	430 x 401 x 161 mm
Power requirements	230 V, 50/60 Hz
Supported radio bands	FM, MW
Radio Data System (RDS)	Yes
I/O ports	5.1 Analogue Input - 1.0 Audio Input - 3.0 Audio Input Front - 1 AV, S-Video Audio Output - 1.0 Control A1 / A1 II Digital Input: coaxial - 1.0 Digital Input: optical - 4.0 Digital Output: optical - 1.0 Headphone Output Monitor Output (Picture): FBAS - 1.0 Monitor Output (Picture): S-Video - 1.0 Phono Input Speaker Selector A S-Video Input - 4.0 S-Video Output - 1.0 Video Input - 5.0 Video Output - 2.0
Connectivity technology	Wired
Power consumption (standby)	0.5 W
Power consumption (typical)	290 W

Weight and Dimensions

Weight	12500 g
