Sony STR-DB790 - Electrical Parts List

9
STR-DA1000ES/DB790
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4733-533-A MAIN BOARD, COMPLETE (DA1000ES)
A-4733-553-A MAIN BOARD, COMPLETE
(DB790: SP, MY, TW, KR, CH)
A-4733-568-A MAIN BOARD, COMPLETE
(DB790: AEP, UK, AUS)
*********************
< CAPACITOR >
C401 1-112-083-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C401 1-112-129-11 ELECT 100uF 20% 25V
(DB790: AEP, UK, AUS)
C401 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C402 1-102-110-00 CERAMIC 220PF 10% 50V
C403 1-112-109-11 ELECT 22uF 20% 100V
(DB790: SP, MY, TW, KR, CH)
C403 1-112-151-11 ELECT 22uF 20% 100V
(DB790: AEP, UK, AUS)
C403 1-128-560-11 ELECT 22uF 20% 100V
(DA1000ES)
C404 1-112-109-11 ELECT 22uF 20% 100V
(DB790: SP, MY, TW, KR, CH)
C404 1-112-151-11 ELECT 22uF 20% 100V
(DB790: AEP, UK, AUS)
C404 1-128-560-11 ELECT 22uF 20% 100V
(DA1000ES)
C413 1-127-876-11 CERAMIC 0.01uF 10% 50V
C416 1-136-161-00 MYLAR 0.047uF 5% 50V
C417 1-136-165-00 MYLAR 0.1uF 5% 50V
C418 1-112-122-11 ELECT 220uF 20% 16V
(DB790: AEP, UK, AUS)
C418 1-112-416-11 ELECT 220uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C418 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C419 1-128-809-11 CERAMIC 100PF 5% 50V
C431 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C431 1-112-089-11 ELECT 47uF 20% 25V
(DB790: SP, MY, TW, KR, CH)
C431 1-112-128-11 ELECT 47uF 20% 25V
(DB790: AEP, UK, AUS)
C432 1-128-813-11 CERAMIC 220PF 5% 50V
C456 1-112-083-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C456 1-112-129-11 ELECT 100uF 20% 25V
(DB790: AEP, UK, AUS)
C456 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C457 1-102-110-00 CERAMIC 220PF 10% 50V
C463 1-127-876-11 CERAMIC 0.01uF 10% 50V
C466 1-136-161-00 MYLAR 0.047uF 5% 50V
C467 1-136-165-00 MYLAR 0.1uF 5% 50V
C468 1-112-122-11 ELECT 220uF 20% 16V
(DB790: AEP, UK, AUS)
C468 1-112-416-11 ELECT 220uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C468 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C481 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C481 1-112-089-11 ELECT 47uF 20% 25V
(DB790: SP, MY, TW, KR, CH)
C481 1-112-128-11 ELECT 47uF 20% 25V
(DB790: AEP, UK, AUS)
C482 1-128-813-11 CERAMIC 220PF 5% 50V
C501 1-112-083-11 ELECT 100uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C501 1-112-129-11 ELECT 100uF 20% 25V
(DB790: AEP, UK, AUS)
C501 1-126-933-11 ELECT 100uF 20% 16V
(DA1000ES)
C502 1-102-110-00 CERAMIC 220PF 10% 50V
C513 1-127-876-11 CERAMIC 0.01uF 10% 50V
C516 1-136-161-00 MYLAR 0.047uF 5% 50V
C517 1-136-165-00 MYLAR 0.1uF 5% 50V
C518 1-112-122-11 ELECT 220uF 20% 16V
(DB790: AEP, UK, AUS)
C518 1-112-416-11 ELECT 220uF 20% 16V
(DB790: SP, MY, TW, KR, CH)
C518 1-126-934-11 ELECT 220uF 20% 16V
(DA1000ES)
C519 1-128-809-11 CERAMIC 100PF 5% 50V
C531 1-126-947-11 ELECT 47uF 20% 35V
(DA1000ES)
C531 1-112-089-11 ELECT 47uF 20% 25V
(DB790: SP, MY, TW, KR, CH)
4. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS
uF: µF
• COILS
uH: µH
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• SEMICONDUCTORS
In each case, u: µ, for example:
uA... : µA... uPA... : µPA...
uPB... : µPB... uPC... : µPC...
uPD... : µPD...
• Abbreviation
AUS: Australian model
CND : Canadian model
CH : Chinese model
KR : Korean model
MY : Malaysia model
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque 0
sont critiquens pour la sécurité.
Ne les remplacer que par une pièce portant le
numéro spécifié.
When indicating parts by reference number,
please include the board.
SP : Singapore model
TW : Taiwan model
MAIN
