STR-DA1000ES/DB790
• Semiconductor Location
– MAIN Board –
Ref. No. LocationRef. No. Location
D411 C-9
D431 I-10
D461 C-9
D481 I-9
D511 D-9
D531 I-3
D561 C-9
D581 H-2
D611 B-10
D631 I-7
D661 B-9
D681 I-5
D711 B-10
D731 G-10
D805 F-10
D807 F-9
D808 F-10
D810 D-6
D812 D-2
D814 E-9
D815 F-2
D816 D-2
D817 F-9
D818 E-2
D819 D-2
D820 D-2
D821 B-9
D822 B-9
D823 B-9
IC401 E-8
IC402 E-7
IC501 F-4
Ref. No. Location
IC502 F-3
IC601 F-8
IC602 F-7
IC651 F-6
IC652 F-5
IC804 D-4
IC805 D-3
Q401 C-4
Q402 J-11
Q403 J-12
Q431 J-11
Q432 I-10
Q433 I-10
Q434 I-11
Q451 C-4
Q452 J-9
Q453 J-10
Q481 J-9
Q482 I-8
Q483 I-9
Q484 I-9
Q501 B-4
Q502 J-4
Q503 J-5
Q531 J-4
Q532 I-3
Q533 I-4
Q534 I-4
Q551 B-4
Q552 J-2
Q553 J-3
Q581 J-2
Q582 H-2
Q583 H-2
Q584 I-2
Q601 C-4
Q602 J-7
Q603 J-8
Q631 J-8
Q632 I-6
Q633 I-7
Q634 I-8
Q651 B-4
Q652 J-5
Q653 J-6
Q681 J-6
Q682 I-5
Q683 I-5
Q684 I-6
Q701 B-5
Q732 G-11
Q751 C-4
Q802 F-9
Q803 F-10
Q805 F-10
Q807 D-8
Q808 B-8
Q809 B-8
Q810 E-3
Q811 B-12
Q813 E-2
Q822 B-9
Q823 D-8
Q824 F-2
Q826 D-6
