69
STR-DA1000ES/DB790
Pin No.
Pin Name
I/O Description
91, 92
SELECT1,
SELECT2
O
Digital input selection signal output terminal
93 XMODE
O
System reset signal output to the digital audio interface receiver “L”: reset
94 CKSEL1
O
Output clock selection signal output to the digital audio interface receiver
95 CLK
O
Clock signal output to the digital audio interface receiver
96 CE
O
Chip enable signal output to the digital audio interface receiver
97
DI
O
Write data output to the digital audio interface receiver
98 DO
I
Read data input from the digital audio interface receiver
99 ERROR
I
PLL lock error signal and data error flag input from the digital audio interface receiver
100 XSTATE
I
Source clock selection monitor input from the digital audio interface receiver
