96
STR-DA1000ES/DB790
CN417 1-779-978-11 PIN, CONNECTOR 3P
CN420 1-770-379-11 CONNECTOR, BOARD TO BOARD 6P
CN421 1-770-379-11 CONNECTOR, BOARD TO BOARD 6P
CN423 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
(DA1000ES)
* CN432 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN482 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN501 1-770-382-11 CONNECTOR, BOARD TO BOARD 12P
* CN532 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
* CN582 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN601 1-770-379-11 CONNECTOR, BOARD TO BOARD 6P
* CN632 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
CN651 1-770-381-11 CONNECTOR, BOARD TO BOARD 10P
* CN682 1-564-704-11 PIN, CONNECTOR (SMALL TYPE) 2P
< DIODE >
D411 8-719-991-33 DIODE 1SS133T-77
D431 8-719-991-33 DIODE 1SS133T-77
D461 8-719-991-33 DIODE 1SS133T-77
D481 8-719-991-33 DIODE 1SS133T-77
D511 8-719-991-33 DIODE 1SS133T-77
D531 8-719-991-33 DIODE 1SS133T-77
D561 8-719-991-33 DIODE 1SS133T-77
D581 8-719-991-33 DIODE 1SS133T-77
D611 8-719-991-33 DIODE 1SS133T-77
D631 8-719-991-33 DIODE 1SS133T-77
D661 8-719-991-33 DIODE 1SS133T-77
D681 8-719-991-33 DIODE 1SS133T-77
D711 8-719-991-33 DIODE 1SS133T-77 (DA1000ES)
D731 8-719-991-33 DIODE 1SS133T-77 (DA1000ES)
D805 8-719-991-33 DIODE 1SS133T-77
D807 8-719-991-33 DIODE 1SS133T-77
D808 8-719-991-33 DIODE 1SS133T-77
D810 8-719-991-33 DIODE 1SS133T-77
D812 8-719-991-33 DIODE 1SS133T-77
D814 8-719-991-33 DIODE 1SS133T-77
D815 8-719-985-88 DIODE HZS6B2LTA
D816 8-719-991-33 DIODE 1SS133T-77
D817 8-719-991-33 DIODE 1SS133T-77
D818 8-719-991-33 DIODE 1SS133T-77
D819 8-719-991-33 DIODE 1SS133T-77
D820 8-719-991-33 DIODE 1SS133T-77
D821 8-719-110-56 DIODE RD22ESB1
D822 8-719-110-56 DIODE RD22ESB1
D823 8-719-922-45 DIODE MTZJ-T-73-5.6C
< GROUND TERMINAL >
EB403 4-924-264-01 TERMINAL, MOUNT
< IC >
IC401 6-702-387-01 IC CXD9725M
IC402 8-759-167-88 IC NJM4565D
IC501 6-702-387-01 IC CXD9725M
IC502 8-759-167-88 IC NJM4565D
IC601 6-702-387-01 IC CXD9725M
IC602 8-759-167-88 IC NJM4565D
IC651 6-702-387-01 IC CXD9725M
IC652 8-759-167-88 IC NJM4565D
IC804 8-759-243-51 IC TC74ACT08P
IC805 8-759-243-51 IC TC74ACT08P
< TRANSISTOR >
Q401 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q431 8-729-044-08 TRANSISTOR 2SD1915 (F) -T (TA).SO
Q432 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q433 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q451 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q481 8-729-044-08 TRANSISTOR 2SD1915 (F) -T (TA).SO
Q482 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q483 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q501 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q531 8-729-044-08 TRANSISTOR 2SD1915 (F) -T (TA).SO
Q532 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q533 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q551 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q581 8-729-044-08 TRANSISTOR 2SD1915 (F) -T (TA).SO
Q582 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q583 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q601 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q631 8-729-044-08 TRANSISTOR 2SD1915 (F) -T (TA).SO
Q632 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q633 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q651 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q681 8-729-044-08 TRANSISTOR 2SD1915 (F) -T (TA).SO
Q682 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q683 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q701 8-729-141-30 TRANSISTOR 2SC3623A-LK (DA1000ES)
Q732 8-729-140-82 TRANSISTOR 2SA988-PAFAEA(DA1000ES)
Q751 8-729-141-30 TRANSISTOR 2SC3623A-LK
Q802 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q803 8-729-140-82 TRANSISTOR 2SA988-PAFAEA
Q805 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q807 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q808 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q809 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q810 8-729-900-63 TRANSISTOR DTA124ES
Q811 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q813 8-729-900-63 TRANSISTOR DTA124ES
Q822 8-729-900-36 TRANSISTOR DTC124ES
Q823 8-729-119-79 TRANSISTOR 2SC2785-FEK
Q824 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q826 8-729-119-79 TRANSISTOR 2SC2785-FEK
< RESISTOR >
R401 1-249-427-11 CARBON 6.8K 5% 1/4W
R402 1-249-417-11 CARBON 1K 5% 1/4W
R403 1-249-441-11 CARBON 100K 5% 1/4W
R404 1-249-417-11 CARBON 1K 5% 1/4W
0R412 1-249-405-11 CARBON 100 5% 1/4W F
0R413 1-249-405-11 CARBON 100 5% 1/4W F
0R414 1-234-182-11 ENCAPSULATED COMPONENT 0.22 5W F
(DA1000ES)
0R414 1-234-572-21 ENCAPSULATED COMPONENT 0.22 5W F
(DB790)
R415 1-249-437-11 CARBON 47K 5% 1/4W
R416 1-249-441-11 CARBON 100K 5% 1/4W
MAIN
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part num-
ber specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
