Sony STR-DB798 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
81
STR-DB798
C310 1-126-960-11 ELECT 1uF 20% 50V
C311 1-126-960-11 ELECT 1uF 20% 50V
C312 1-126-960-11 ELECT 1uF 20% 50V
C313 1-126-960-11 ELECT 1uF 20% 50V
C317 1-126-947-11 ELECT 47uF 20% 35V
C330 1-127-888-11 CERAMIC 0.1uF 10% 50V
C331 1-127-888-11 CERAMIC 0.1uF 10% 50V
C338 1-126-947-11 ELECT 47uF 20% 35V
C350 1-127-876-11 CERAMIC 0.01uF 10% 50V
C352 1-127-888-11 CERAMIC 0.1uF 10% 50V
C353 1-104-665-11 ELECT 100uF 20% 25V
C354 1-127-876-11 CERAMIC 0.01uF 10% 50V
C355 1-126-956-11 ELECT 0.1uF 20% 50V
C356 1-127-876-11 CERAMIC 0.01uF 10% 50V
C357 1-127-876-11 CERAMIC 0.01uF 10% 50V
C358 1-162-201-31 CERAMIC 12PF 5% 50V
C360 1-128-818-11 CERAMIC 560PF 5% 50V
C361 1-128-816-11 CERAMIC 390PF 5% 50V
C362 1-126-935-11 ELECT 470uF 20% 16V
C363 1-128-801-11 CERAMIC 22PF 5% 50V
C364 1-162-201-31 CERAMIC 12PF 5% 50V
C365 1-126-947-11 ELECT 47uF 20% 35V
C366 1-127-888-11 CERAMIC 0.1uF 10% 50V
C367 1-127-876-11 CERAMIC 0.01uF 10% 50V
C368 1-126-963-11 ELECT 4.7uF 20% 50V
C369 1-130-495-00 MYLAR 0.1uF 5% 50V
C371 1-128-801-11 CERAMIC 22PF 5% 50V
C372 1-162-201-31 CERAMIC 12PF 5% 50V
C373 1-128-801-11 CERAMIC 22PF 5% 50V
C374 1-126-935-11 ELECT 470uF 20% 16V
C375 1-126-965-11 ELECT 22uF 20% 50V
C376 1-126-947-11 ELECT 47uF 20% 35V
C377 1-127-888-11 CERAMIC 0.1uF 10% 50V
C378 1-127-888-11 CERAMIC 0.1uF 10% 50V
C379 1-128-812-11 CERAMIC 180PF 5% 50V
C380 1-127-876-11 CERAMIC 0.01uF 10% 50V
C381 1-127-876-11 CERAMIC 0.01uF 10% 50V
C382 1-127-888-11 CERAMIC 0.1uF 10% 50V
C383 1-104-665-11 ELECT 100uF 20% 25V
C384 1-127-888-11 CERAMIC 0.1uF 10% 50V
C385 1-127-876-11 CERAMIC 0.01uF 10% 50V
C386 1-104-665-11 ELECT 100uF 20% 25V
C387 1-127-876-11 CERAMIC 0.01uF 10% 50V
C388 1-127-876-11 CERAMIC 0.01uF 10% 50V
C389 1-127-888-11 CERAMIC 0.1uF 10% 50V
C390 1-104-665-11 ELECT 100uF 20% 25V
C391 1-126-947-11 ELECT 47uF 20% 35V
C392 1-127-888-11 CERAMIC 0.1uF 10% 50V
C393 1-162-203-31 CERAMIC 15PF 5% 50V
C394 1-126-961-11 ELECT 2.2uF 20% 50V
C395 1-127-876-11 CERAMIC 0.01uF 10% 50V
C396 1-126-963-11 ELECT 4.7uF 20% 50V
C397 1-127-876-11 CERAMIC 0.01uF 10% 50V
C398 1-128-806-11 CERAMIC 56PF 5% 50V
C399 1-126-964-11 ELECT 10uF 20% 50V
C952 1-126-947-11 ELECT 47uF 20% 35V
C953 1-136-169-00 MYLAR 0.22uF 5% 50V
C954 1-127-888-11 CERAMIC 0.1uF 10% 50V
5
C955 1-136-169-00 MYLAR 0.22uF 5% 50V
C956 1-126-935-11 ELECT 470uF 20% 16V
C3801 1-126-933-11 ELECT 100uF 20% 16V
C3802 1-127-888-11 CERAMIC 0.1uF 10% 50V
C3803 1-126-933-11 ELECT 100uF 20% 16V
C3804 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN918 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
CN919 1-778-226-21 CONNECTOR, BOARD TO BOARD 6P
CN3801 1-573-843-11 CONNECTOR, BOARD TO BOARD 11P
CNP3052 1-784-926-11 PIN, CONNECTOR 11P
< FERRITE BEAD >
FB353 1-412-911-11 INDUCTOR, FERRITE BEAD
FB354 1-412-911-11 INDUCTOR, FERRITE BEAD
< IC >
IC370 6-701-597-01 IC TC90A69NG
IC371 6-706-778-01 IC MM1093PFB (AEP, UK)
IC371 8-759-826-19 IC MM1093NF (TW)
IC372 6-803-031-01 IC NJM2268D
IC951 8-759-245-79 IC TA79005S
IC952 8-759-231-53 IC TA7805S
IC1304 6-706-767-01 IC NJM2586AM
< JACK >
J301 1-817-726-11 JACK, PIN 9P
(COMPONENT VIDEO ASSINABLE TV/SAT/DVD IN,
COMPONENT VIDEO ASSINABLE MONITOR OUT)
< COIL >
L370 1-410-514-11 INDUCTOR 27uH
L371 1-410-514-11 INDUCTOR 27uH
L372 1-414-189-31 INDUCTOR 100uH
L373 1-414-189-31 INDUCTOR 100uH
L374 1-410-514-11 INDUCTOR 27uH
L375 1-410-513-11 INDUCTOR 22uH (AEP, UK)
L375 1-410-515-11 INDUCTOR 33uH (TW)
L376 1-414-189-31 INDUCTOR 100uH
L377 1-414-189-31 INDUCTOR 100uH
< TRANSISTOR >
Q371 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q372 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q373 8-729-119-78 TRANSISTOR 2SC2785-HFE
Q953 8-729-140-98 TRANSISTOR 2SD773-34
Q954 8-729-029-23 TRANSISTOR DTA114TSA-TP
Q955 8-729-029-86 TRANSISTOR DTC124ESA
Q956 8-729-029-86 TRANSISTOR DTC124ESA
Q957 8-729-140-93 TRANSISTOR 2SB733-34
< RESISTOR >
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
COMP-V

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
