Sony STR-DB798 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
82
STR-DB798
DC PWR
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
R308 1-247-804-11 CARBON 75 5% 1/4W
R309 1-247-804-11 CARBON 75 5% 1/4W
R313 1-249-417-11 CARBON 1K 5% 1/4W
R358 1-249-417-11 CARBON 1K 5% 1/4W
R359 1-249-417-11 CARBON 1K 5% 1/4W
R363 1-247-903-00 CARBON 1M 5% 1/4W
R365 1-247-807-31 CARBON 100 5% 1/4W
R366 1-247-807-31 CARBON 100 5% 1/4W
R367 1-249-429-11 CARBON 10K 5% 1/4W
R368 1-247-843-11 CARBON 3.3K 5% 1/4W
R369 1-247-843-11 CARBON 3.3K 5% 1/4W
R373 1-249-416-11 CARBON 820 5% 1/4W
R374 1-247-903-00 CARBON 1M 5% 1/4W
R375 1-249-424-11 CARBON 3.9K 5% 1/4W
R376 1-249-417-11 CARBON 1K 5% 1/4W
R377 1-249-416-11 CARBON 820 5% 1/4W
R378 1-249-416-11 CARBON 820 5% 1/4W
R379 1-249-416-11 CARBON 820 5% 1/4W
R382 1-249-418-11 CARBON 1.2K 5% 1/4W
R383 1-249-420-11 CARBON 1.8K 5% 1/4W
R384 1-249-424-11 CARBON 3.9K 5% 1/4W
R385 1-249-416-11 CARBON 820 5% 1/4W
R386 1-249-429-11 CARBON 10K 5% 1/4W
R387 1-249-429-11 CARBON 10K 5% 1/4W
R388 1-249-412-11 CARBON 390 5% 1/4W
R389 1-249-412-11 CARBON 390 5% 1/4W
R390 1-247-903-00 CARBON 1M 5% 1/4W
R391 1-249-431-11 CARBON 15K 5% 1/4W
R392 1-247-847-11 CARBON 4.7K 5% 1/4W
(AEP, UK)
R392 1-249-426-11 CARBON 5.6K 5% 1/4W
(TW)
R393 1-249-430-11 CARBON 12K 5% 1/4W
R394 1-249-430-11 CARBON 12K 5% 1/4W
R954 1-249-417-11 CARBON 1K 5% 1/4W
R955 1-249-415-11 CARBON 680 5% 1/4W
R956 1-249-429-11 CARBON 10K 5% 1/4W
R959 1-249-429-11 CARBON 10K 5% 1/4W
< VIBRATOR >
X371 1-781-134-21 VIBRATOR, CRYSTAL (4.43MHz) (AEP, UK)
X371 1-781-342-21 OSCILLATOR, CRYSTAL (3.5795MHz) (TW)
************************************************************
DC PWR BOARD
*************
1-533-399-31 FUSE HOLDER
< CAPACITOR >
C902 1-112-137-11 ELECT 2200uF 20% 35V
C903 1-112-136-11 ELECT 1000uF 20% 35V
C904 1-104-665-11 ELECT 100uF 20% 25V
C906 1-126-947-11 ELECT 47uF 20% 35V
C907 1-112-126-11 ELECT 4700uF 20% 16V
C908 1-112-124-11 ELECT 1000uF 20% 16V
C909 1-126-970-11 ELECT 330uF 20% 50V
C915 1-112-031-11 ELECT (BLOCK) 8200uF 20% 63V
C916 1-112-031-11 ELECT (BLOCK) 8200uF 20% 63V
C917 1-137-350-11 FILM 0.015uF 5% 100V
C918 1-137-350-11 FILM 0.015uF 5% 100V
C919 1-104-999-11 MYLAR 0.1uF 5% 200V
C920 1-127-888-11 CERAMIC 0.1uF 10% 50V
C923 1-104-666-11 ELECT 220uF 20% 25V
C924 1-104-666-11 ELECT 220uF 20% 25V
C925 1-104-666-11 ELECT 220uF 20% 25V
C926 1-104-666-11 ELECT 220uF 20% 25V
< CONNECTOR >
CN906 1-691-768-11 PLUG (MICRO CONNECTOR) 6P
* CN907 1-691-772-11 PLUG (MICRO CONNECTOR) 10P
CN909 1-784-922-11 PIN, CONNECTOR 5P
CN910 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
CN911 1-785-101-11 PIN, CONNECTOR (3.96mm PITCH) 3P
CN912 1-778-226-21 CONNECTOR, BOARD TO BOARD 6P
CN913 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D902 8-719-933-95 DIODE HZS20-1L
D903 8-719-063-70 DIODE D1NL20U
D904 8-719-063-70 DIODE D1NL20U
D905 8-719-063-70 DIODE D1NL20U
D906 8-719-063-70 DIODE D1NL20U
D908 6-501-068-01 DIODE D4SBN20-7001
D909 6-500-522-11 DIODE 10EDB40-TA2B5
D912 6-500-522-11 DIODE 10EDB40-TA2B5
D913 6-500-522-11 DIODE 10EDB40-TA2B5
D914 6-501-003-21 DIODE D6SBN20-7003
D915 6-500-522-11 DIODE 10EDB40-TA2B5
D916 6-500-522-11 DIODE 10EDB40-TA2B5
< EARTH TERMINAL >
* EB901 1-537-738-21 TERMINAL, EARTH
< TRANSISTOR >
Q903 8-729-041-38 TRANSISTOR 2SB1241-Q-TV2
< RESISTOR >
R902 1-247-863-11 CARBON 22K 5% 1/4W
R904 1-249-429-11 CARBON 10K 5% 1/4W
0R910 1-249-385-11 CARBON 2.2 5% 1/4W F
0R911 1-216-349-81 METAL OXIDE 1 5% 1W F
0R912 1-216-349-81 METAL OXIDE 1 5% 1W F
0R913 1-249-407-11 CARBON 150 5% 1/4W F
************************************************************
A-1112-103-A DIGITAL BOARD, COMPLETE (AEP, UK)
A-1112-143-A DIGITAL BOARD, COMPLETE (TW)
***********************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
COMP-V DIGITAL
