Sony STR-DB798 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
93
STR-DB798
0R493 1-249-393-11 CARBON 10 5% 1/4W F
0R498 1-249-393-11 CARBON 10 5% 1/4W F
0R499 1-249-393-11 CARBON 10 5% 1/4W F
0R547 1-249-393-11 CARBON 10 5% 1/4W F
0R548 1-249-393-11 CARBON 10 5% 1/4W F
0R549 1-249-393-11 CARBON 10 5% 1/4W F
0R598 1-249-393-11 CARBON 10 5% 1/4W F
0R599 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY444 1-515-920-11 RELAY (24V)
RY449 1-515-920-11 RELAY (24V)
RY549 1-515-920-11 RELAY (24V)
< TERMINAL >
TM449 1-780-033-11 TERMINAL BOARD (SP) (8P)
(SPEAKERS FRONT B/SURR)
TM699 1-694-933-21 TERMINAL BOARD (SP) (4P)
(SPEAKERS FRONT A)
************************************************************
SPK-B BOARD
***********
< CAPACITOR >
C494 1-128-809-11 CERAMIC 100PF 5% 50V
C648 1-128-809-11 CERAMIC 100PF 5% 50V
C649 1-127-876-11 CERAMIC 0.01uF 10% 50V
C699 1-127-876-11 CERAMIC 0.01uF 10% 50V
C748 1-127-871-11 CERAMIC 3900PF 10% 50V
C749 1-127-876-11 CERAMIC 0.01uF 10% 50V
C810 1-127-868-11 CERAMIC 2200PF 10% 50V
< CONNECTOR >
CN443 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
CN444 1-770-726-11 CONNECTOR, BOARD TO BOARD 6P
CN451 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D649 8-719-991-33 DIODE 1SS133T-77
D699 8-719-991-33 DIODE 1SS133T-77
D810 8-719-991-33 DIODE 1SS133T-77
< JACK >
J803 1-770-377-31 JACK, PIN 1P (SUB WOOFER AUDIO OUT)
< COIL >
L649 1-420-872-52 COIL, AIR-CORE
L699 1-420-872-52 COIL, AIR-CORE
L749 1-420-872-52 COIL, AIR-CORE
< RESISTOR >
0R647 1-249-393-11 CARBON 10 5% 1/4W F
0R648 1-249-393-11 CARBON 10 5% 1/4W F
0R649 1-249-393-11 CARBON 10 5% 1/4W F
0R697 1-249-393-11 CARBON 10 5% 1/4W F
0R698 1-249-393-11 CARBON 10 5% 1/4W F
0R699 1-249-393-11 CARBON 10 5% 1/4W F
0R748 1-249-393-11 CARBON 10 5% 1/4W F
0R749 1-249-393-11 CARBON 10 5% 1/4W F
R809 1-249-417-11 CARBON 1K 5% 1/4W
0R829 1-249-393-11 CARBON 10 5% 1/4W F
< RELAY >
RY649 1-515-920-11 RELAY (24V)
RY699 1-515-920-11 RELAY (24V)
RY807 1-755-483-11 RELAY
< TERMINAL >
TM444 1-780-038-11 TERMINAL BOARD (SP) (6P)
(SPEAKERS CENTER/SURR BACK)
************************************************************
STAY-1 BOARD
************
< CONNECTOR >
CN28 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
************************************************************
STAY-2 BOARD
************
< CONNECTOR >
CN38 1-770-011-41 CONNECTOR, BOARD TO BOARD 4P
************************************************************
STAY-5 BOARD
************
< CONNECTOR >
CN168 1-778-226-21 CONNECTOR, BOARD TO BOARD 6P
CN178 1-778-227-41 CONNECTOR, BOARD TO BOARD 6P
************************************************************
A-1112-100-A S-VIDEO BOARD, COMPLETE
***********************
< CAPACITOR >
C850 1-128-805-11 CERAMIC 47PF 5% 50V
C851 1-128-805-11 CERAMIC 47PF 5% 50V
C852 1-128-805-11 CERAMIC 47PF 5% 50V
C853 1-128-805-11 CERAMIC 47PF 5% 50V
C854 1-127-868-11 CERAMIC 2200PF 10% 50V
C855 1-136-165-00 MYLAR 0.1uF 5% 50V
C856 1-136-165-00 MYLAR 0.1uF 5% 50V
C857 1-136-165-00 MYLAR 0.1uF 5% 50V
C858 1-126-964-11 ELECT 10uF 20% 50V
C859 1-126-964-11 ELECT 10uF 20% 50V
C860 1-126-964-11 ELECT 10uF 20% 50V
C861 1-127-868-11 CERAMIC 2200PF 10% 50V
C862 1-127-868-11 CERAMIC 2200PF 10% 50V
C863 1-127-888-11 CERAMIC 0.1uF 10% 50V
C864 1-136-165-00 MYLAR 0.1uF 5% 50V
C867 1-127-888-11 CERAMIC 0.1uF 10% 50V
C868 1-127-868-11 CERAMIC 2200PF 10% 50V
C869 1-127-888-11 CERAMIC 0.1uF 10% 50V
C870 1-126-964-11 ELECT 10uF 20% 50V
SPK-A
SPK-B
STAY-5STAY-2STAY-1 S-VIDEO

Sony STR-DB798 Specifications

General

Impedance	8 Ω
Supported radio bands	FM
Radio Data System (RDS)	Yes
Channels quantity	7 channels
I/O ports	Output(Component x 1, Optical Digital x 1, Composite x 1, S-Video x 1), Input(Component x 2, Optical Digital x 4, S-Video x 4, Coaxial Digital x 2, Composite x 4)
