Sony STR-DB798 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
94
STR-DB798
C871 1-126-786-11 ELECT 47uF 20% 16V
C872 1-127-888-11 CERAMIC 0.1uF 10% 50V
C873 1-126-786-11 ELECT 47uF 20% 16V
C877 1-127-888-11 CERAMIC 0.1uF 10% 50V
C878 1-126-916-11 ELECT 1000uF 20% 6.3V
C879 1-126-960-11 ELECT 1uF 20% 50V
C880 1-128-805-11 CERAMIC 47PF 5% 50V
C881 1-128-805-11 CERAMIC 47PF 5% 50V
C882 1-126-964-11 ELECT 10uF 20% 50V
C883 1-136-165-00 MYLAR 0.1uF 5% 50V
C890 1-104-665-11 ELECT 100uF 20% 25V
< CONNECTOR >
CN851 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
* CN853 1-564-720-11 PIN, CONNECTOR (SMALL TYPE) 4P
CN854 1-573-825-11 CONNECTOR, BOARD TO BOARD 11P
< DIODE >
D850 8-719-991-33 DIODE 1SS133T-77
D851 8-719-991-33 DIODE 1SS133T-77
D852 8-719-991-33 DIODE 1SS133T-77
D853 8-719-991-33 DIODE 1SS133T-77
< IC >
IC850 6-701-890-01 IC NJM2595D
IC851 6-701-890-01 IC NJM2595D
IC852 8-759-822-05 IC LA7213
< JACK >
J850 1-794-937-11 CONNECTOR (DIN) 2P (VIDEO DVD/TV/SAT
S-VIDEO IN)
J851 1-537-943-11 CONNECTOR (DIN) 1P (VIDEO MONITOR
S-VIDEO OUT)
J852 1-794-937-11 CONNECTOR (DIN) 2P (VIDEO VIDEO 1
S-VIDEO IN/OUT)
J853 1-794-937-11 CONNECTOR (DIN) 2P (VIDEO VIDEO 2
S-VIDEO IN/OUT)
< TRANSISTOR >
Q850 8-729-029-66 TRANSISTOR DTC114ESA
Q851 8-729-201-53 TRANSISTOR 2SA1015-GR
< RESISTOR >
R854 1-247-804-11 CARBON 75 5% 1/4W
R855 1-247-804-11 CARBON 75 5% 1/4W
R856 1-247-804-11 CARBON 75 5% 1/4W
R857 1-247-804-11 CARBON 75 5% 1/4W
R858 1-247-804-11 CARBON 75 5% 1/4W
R859 1-247-804-11 CARBON 75 5% 1/4W
R860 1-247-804-11 CARBON 75 5% 1/4W
R861 1-247-804-11 CARBON 75 5% 1/4W
R862 1-247-804-11 CARBON 75 5% 1/4W
R863 1-247-804-11 CARBON 75 5% 1/4W
R864 1-247-883-00 CARBON 150K 5% 1/4W
R865 1-249-411-11 CARBON 330 5% 1/4W
R866 1-249-421-11 CARBON 2.2K 5% 1/4W
R867 1-249-429-11 CARBON 10K 5% 1/4W
R882 1-247-804-11 CARBON 75 5% 1/4W
R883 1-247-804-11 CARBON 75 5% 1/4W
R884 1-247-804-11 CARBON 75 5% 1/4W
R885 1-247-804-11 CARBON 75 5% 1/4W
< RELAY >
RY850 1-755-359-11 RELAY
************************************************************
VIDEO BOARD
***********
< CAPACITOR >
C301 1-128-805-11 CERAMIC 47PF 5% 50V
C302 1-127-868-11 CERAMIC 2200PF 10% 50V
C303 1-126-964-11 ELECT 10uF 20% 50V
C304 1-127-868-11 CERAMIC 2200PF 10% 50V
C305 1-128-805-11 CERAMIC 47PF 5% 50V
C306 1-126-964-11 ELECT 10uF 20% 50V
C307 1-128-805-11 CERAMIC 47PF 5% 50V
C308 1-127-868-11 CERAMIC 2200PF 10% 50V
C309 1-126-964-11 ELECT 10uF 20% 50V
C310 1-126-964-11 ELECT 10uF 20% 50V
C311 1-127-888-11 CERAMIC 0.1uF 10% 50V
C313 1-126-964-11 ELECT 10uF 20% 50V
C315 1-127-888-11 CERAMIC 0.1uF 10% 50V
< CONNECTOR >
CN301 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
< DIODE >
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
< IC >
IC301 6-701-890-01 IC NJM2595D
< JACK >
J302 1-794-970-11 JACK, PIN 1P (VIDEO MONITOR VIDEO OUT)
J304 1-794-978-11 JACK, PIN 3P (VIDEO VIDEO 1 VIDEO
IN/OUT, VIDEO VIDEO 2 VIDEO IN)
J305 1-794-978-11 JACK, PIN 3P (VIDEO VIDEO 2 VIDEO OUT,
VIDEO DVD/TV/SAT VIDEO IN)
< RESISTOR >
R301 1-247-804-11 CARBON 75 5% 1/4W
R302 1-247-804-11 CARBON 75 5% 1/4W
R303 1-247-804-11 CARBON 75 5% 1/4W
R304 1-247-804-11 CARBON 75 5% 1/4W
R305 1-247-804-11 CARBON 75 5% 1/4W
R306 1-247-804-11 CARBON 75 5% 1/4W
R307 1-247-804-11 CARBON 75 5% 1/4W
************************************************************
VIDEO-AU BOARD
**************
< CAPACITOR >
C201 1-127-868-11 CERAMIC 2200PF 10% 50V
VIDEOS-VIDEO VIDEO-AU
