Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
95
STR-DB798
C211 1-127-880-11 CERAMIC 0.022uF 10% 50V
C212 1-127-880-11 CERAMIC 0.022uF 10% 50V
C213 1-128-809-11 CERAMIC 100PF 5% 50V
C214 1-127-876-11 CERAMIC 0.01uF 10% 50V
C215 1-127-868-11 CERAMIC 2200PF 10% 50V
< CONNECTOR >
CN201 1-766-719-41 CONNECTOR, BOARD TO BOARD 10P
* CN202 1-564-719-11 PIN, CONNECTOR (SMALL TYPE) 3P
< IC >
IC201 8-759-582-65 IC TC9273N-014
< JACK >
J201 1-774-411-11 JACK, PIN 6P (VIDEO DVD/TV/SAT AUDIO IN,
VIDEO VIDEO 2 AUDIO OUT)
J202 1-774-411-11 JACK, PIN 6P (VIDEO VIDEO 1 AUDIO IN/OUT,
VIDEO VIDEO 2 AUDIO IN)
< RESISTOR >
R201 1-259-428-61 CARBON 1K 5% 1/6W
R202 1-259-428-61 CARBON 1K 5% 1/6W
R203 1-259-436-61 CARBON 2.2K 5% 1/6W
R204 1-259-428-61 CARBON 1K 5% 1/6W
R205 1-259-436-61 CARBON 2.2K 5% 1/6W
R206 1-259-428-61 CARBON 1K 5% 1/6W
0R207 1-249-399-11 CARBON 33 5% 1/4W F
0R208 1-249-399-11 CARBON 33 5% 1/4W F
R211 1-259-428-61 CARBON 1K 5% 1/6W
R219 1-259-428-61 CARBON 1K 5% 1/6W
R220 1-259-428-61 CARBON 1K 5% 1/6W
R251 1-259-428-61 CARBON 1K 5% 1/6W
R252 1-259-428-61 CARBON 1K 5% 1/6W
R253 1-259-436-61 CARBON 2.2K 5% 1/6W
R254 1-259-428-61 CARBON 1K 5% 1/6W
R255 1-259-436-61 CARBON 2.2K 5% 1/6W
R256 1-259-428-61 CARBON 1K 5% 1/6W
************************************************************
VOL BOARD
*********
< CONNECTOR >
CN1060 1-779-978-11 PIN, CONNECTOR 3P
< VARIABLE RESISTOR >
RV1060 1-418-725-41 ENCODER, ROTARY (12 TYPE)
(MASTER VOLUME)
************************************************************
MISCELLANEOUS
**************
53 1-773-002-11 WIRE (FLAT TYPE) (15 CORE)
57 1-693-676-11 TUNER (AEP, UK)
57 1-693-678-11 TUNER (TW)
58 1-469-089-11 CLAMP FILTER (FERRITE CORE)
* 59 1-400-052-11 CLAMP FILTER (FERRITE CORE)
354 1-773-339-11 WIRE (FLAT TYPE) (31 CORE)
0F1 1-532-504-33 FUSE (T4AL/250V) (AEP, UK)
0F1 1-533-312-12 FUSE GLASS CYLINDRICAL (DIA.5)
(10A/125V) (TW)
0F903 1-532-504-33 FUSE (T4AL/250V)
0F904 1-532-504-33 FUSE (T4AL/250V)
Q402 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q403 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q452 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q453 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q502 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q503 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q552 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q553 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q602 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q603 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q652 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q653 6-702-391-01 TRANSISTOR MP1620-OPY-MK
Q702 6-702-390-01 TRANSISTOR MN2488-OPY-MK
Q703 6-702-391-01 TRANSISTOR MP1620-OPY-MK
0T901 1-443-783-11 POWER TRANSFORMER (UK)
0T901 1-443-783-21 POWER TRANSFORMER (AEP)
0T901 1-443-784-11 POWER TRANSFORMER (TW)
************************************************************
ACCESSORIES
************
1-479-214-11 COMMANDER, STANDARD (RM-AAP002)
1-501-374-12 ANTENNA, LOOP (AM)
1-501-807-12 ANTENNA (FM)
0 1-551-631-22 CORD, POWER (AEP)
0 1-824-532-11 POWER-SUPPLY CORD (UK)
0 1-828-109-12 CORD, POWER (TW)
2-598-516-11 INSTRUCTION MANUAL (DB798) (ENGLISH)
2-598-516-21 INSTRUCTION MANUAL (DB798) (FRENCH)
(AEP)
2-598-516-31 INSTRUCTION MANUAL (DB798) (SPANISH)
(AEP)
2-598-516-41 INSTRUCTION MANUAL (DB798)
(GERMAN, DUTCH, SWEDISH) (AEP)
2-598-516-51 INSTRUCTION MANUAL (DB798)
(ITALIAN, POLISH) (AEP)
2-598-516-61 INSTRUCTION MANUAL (DB798)
(TRADITIONAL CHINESE) (TW)
2-598-516-71 INSTRUCTION MANUAL (DB798)
(DANISH, FINNISH) (AEP)
2-598-516-81 INSTRUCTIONMANUAL (DB798)
(PORTUGUESE) (AEP)
2-598-516-91 INSTRUCTION MANUAL (DB798) (RUSSIAN)
(AEP)
2-630-421-01 INSTRUCTION MANUAL (EUROPE) (GREEK)
(AEP)
2-630-421-11 INSTRUCTION MANUAL (EUROPE) (TURKISH)
(AEP)
2-630-421-21 INSTRUCTION MANUAL (EUROPE)
(HUNGARIAN, CZECH) (AEP)
2-630-421-31 INSTRUCTION MANUAL (EUROPE)
(SLOVAKIAN) (AEP)
3-071-119-01 COVER, BATTERY (for RM-AAP002)
VOLVIDEO-AU
