Sony VPL-VW10HT Service Manual

6-11
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R4311 1-216-049-91 RES,CHIP 1K 5% 1/10W
R4312 1-216-049-91 RES,CHIP 1K 5% 1/10W
R4313 1-216-033-00 RES,CHIP 220 5% 1/10W
R4314 1-216-037-00 RES,CHIP 330 5% 1/10W
R4315 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4316 1-216-085-00 RES,CHIP 33K 5% 1/10W
R4317 1-216-295-91 SHORT 0
R4318 1-216-295-91 SHORT 0
R4319 1-216-041-00 RES,CHIP 470 5% 1/10W
R4320 1-216-047-91 RES,CHIP 820 5% 1/10W
R4321 1-216-049-91 RES,CHIP 1K 5% 1/10W
R4322 1-216-017-91 RES,CHIP 47 5% 1/10W
R4323 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4324 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4325 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4326 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4327 1-216-025-91 RES,CHIP 100 5% 1/10W
R4328 1-216-025-91 RES,CHIP 100 5% 1/10W
R4329 1-216-025-91 RES,CHIP 100 5% 1/10W
R4332 1-216-295-91 SHORT 0
R4333 1-216-295-91 SHORT 0
R4334 1-216-295-91 SHORT 0
R4346 1-216-017-91 RES,CHIP 47 5% 1/10W
R4347 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4348 1-216-025-91 RES,CHIP 100 5% 1/10W
R4349 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4350 1-216-089-91 RES,CHIP 47K 5% 1/10W
R4351 1-216-089-91 RES,CHIP 47K 5% 1/10W
R4352 1-216-041-00 RES,CHIP 470 5% 1/10W
R4353 1-216-099-00 RES,CHIP 120K 5% 1/10W
R4354 1-216-089-91 RES,CHIP 47K 5% 1/10W
R4355 1-216-017-91 RES,CHIP 47 5% 1/10W
R4356 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4357 1-216-025-91 RES,CHIP 100 5% 1/10W
R4358 1-216-073-00 RES,CHIP 10K 5% 1/10W
R4359 1-216-049-91 RES,CHIP 1K 5% 1/10W
R4360 1-216-095-00 RES,CHIP 82K 5% 1/10W
R4361 1-216-099-00 RES,CHIP 120K 5% 1/10W
R4362 1-216-089-91 RES,CHIP 47K 5% 1/10W
R4363 1-216-089-91 RES,CHIP 47K 5% 1/10W
R4364 1-216-017-91 RES,CHIP 47 5% 1/10W
R4365 1-216-017-91 RES,CHIP 47 5% 1/10W
R4366 1-216-653-11 METAL CHIP 1.2K 0.50% 1/10W
R4367 1-216-639-11 METAL CHIP 330 0.50% 1/10W
R4368 1-216-653-11 METAL CHIP 1.2K 0.50% 1/10W
R4369 1-216-639-11 METAL CHIP 330 0.50% 1/10W
R4370 1-216-017-91 RES,CHIP 47 5% 1/10W
R4371 1-216-089-91 RES,CHIP 47K 5% 1/10W
R4372 1-216-380-11 METAL OXIDE 8.2 5% 2W F
R4373 1-216-355-11 METAL OXIDE 3.3 5% 1W F
R4374 1-216-017-91 RES,CHIP 47 5% 1/10W
R4375 1-216-017-91 RES,CHIP 47 5% 1/10W
R4376 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R4377 1-216-001-00 RES,CHIP 10 5% 1/10W
R4378 1-216-001-00 RES,CHIP 10 5% 1/10W
R4379 1-216-001-00 RES,CHIP 10 5% 1/10W
R4381 1-216-017-91 RES,CHIP 47 5% 1/10W
R4382 1-216-017-91 RES,CHIP 47 5% 1/10W
R4383 1-216-017-91 RES,CHIP 47 5% 1/10W
<RELAY>
RY4001 1-755-384-21 RELAY
RY4002 1-755-384-21 RELAY
RY4003 1-755-384-21 RELAY
RY4004 1-755-384-21 RELAY
<THERMISTOR>
TH4001 1-809-020-11 THERMISTOR
*************************************************************
* A-1316-491-A G COMPL
**********************
7-682-647-09 SCREW +PS 3X6
7-682-648-09 SCREW +PS 3X8
7-682-650-09 SCREW +PS 3X12
<CAPACITOR>
C2002 1-137-477-11 MYLAR 0.47µF 10% 400V
C2003 ! 1-161-964-61 CERAMIC 0.0047µF250V
C2004 ! 1-161-964-61 CERAMIC 0.0047µF250V
C2005 ! 1-161-964-61 CERAMIC 0.0047µF250V
C2007 1-117-228-11 MYLAR 2.2µF 10% 450V
C2008 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C2009 1-115-340-11 CERAMIC CHIP 0.22µF 10% 25V
C2010 1-107-909-11 ELECT 47µF 20% 50V
C2013 1-135-449-11 ELECT 220µF 20% 450V
C2014 1-135-449-11 ELECT 220µF 20% 450V
C2015 1-117-227-11 MYLAR 1µF 10% 450V
C2016 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C2101 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C2103 1-126-163-11 ELECT 4.7µF 20% 50V
C2104 1-104-830-11 ELECT 10µF 20% 50V
C2105 1-130-495-00 MYLAR 0.1µF 5% 50V
C2106 1-130-029-00 FILM 8200pF 2% 50V
C2107 1-104-830-11 ELECT 10µF 20% 50V
C2108 1-107-909-11 ELECT 47µF 20% 50V
C2109 1-131-974-11 FILM 2200pF 5% 800V
C2110 1-131-974-11 FILM 2200pF 5% 800V
C2111 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C2112 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C2201 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C2202 1-115-743-11 ELECT 0.0033F 20% 10V
C2203 1-115-737-11 ELECT 0.001F 20% 10V
C2204 1-115-743-11 ELECT 0.0033F 20% 10V
C2205 1-115-792-11 ELECT 0.0022F 20% 25V
C2206 1-115-792-11 ELECT 0.0022F 20% 25V
C2207 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C2209 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C2210 1-107-888-11 ELECT 47µF 20% 25V
C2211 1-107-888-11 ELECT 47µF 20% 25V
C2212 1-107-909-11 ELECT 47µF 20% 16V
C2213 1-107-909-11 ELECT 47µF 20% 16V
C2214 1-107-909-11 ELECT 47µF 20% 16V
C2216 1-109-994-11 CERAMIC CHIP 2.2µF 10% 10V
C2301 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C2302 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C2303 1-107-888-11 ELECT 47µF 20% 25V
C2304 1-107-888-11 ELECT 47µF 20% 25V
C2305 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C2306 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C2307 1-128-526-11 ELECT 100µF 20% 16V
C2308 1-128-526-11 ELECT 100µF 20% 16V
C2309 1-107-888-11 ELECT 47µF 20% 25V
C2310 1-107-888-11 ELECT 47µF 20% 25V
C2311 1-107-888-11 ELECT 47µF 20% 25V
