Sony VPL-VW10HT Service Manual

6-12
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
<CONNECTOR>
CN2001 * 1-691-960-21 PIN, CONNECTOR (PC BOARD) 3P
CN2002 * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN2003 1-764-334-11 PLUG, CONNECTOR 11P
CN2004 * 1-564-511-11 PLUG, CONNECTOR 8P
CN2005 * 1-564-509-11 PLUG, CONNECTOR 6P
CN2006 * 1-785-518-11 CONNECTOR, BOARD TO BOARD 15P
CN2007 * 1-774-248-11 CONNECTOR, BOARD TO BOARD 8P
CN2008 * 1-564-507-11 PLUG, CONNECTOR 4P
CN2009 * 1-564-506-11 PLUG, CONNECTOR 3P
CN2010 * 1-564-506-11 PLUG, CONNECTOR 3P
<DIODE>
D2001 ! 8-719-921-19 DIODE 1SS119-25
D2002 8-719-106-88 DIODE RD15M-T1B1
D2003 ! 8-719-066-75 DIODE D6SB80
D2004 8-719-304-63 DIODE RM11C
D2005 8-719-510-02 DIODE D1NS4
D2101 8-719-510-02 DIODE D1NS4
D2102 8-719-979-64 DIODE UF4005PKG23
D2103 8-719-979-64 DIODE UF4005PKG23
D2104 8-719-110-36 DIODE RD13ESB2
D2201 8-719-510-12 DIODE D10SC4M
D2202 8-719-510-12 DIODE D10SC4M
D2203 8-719-510-12 DIODE D10SC4M
D2204 8-719-510-12 DIODE D10SC4M
D2205 8-719-510-02 DIODE D1NS4
D2206 8-719-073-01 DIODE MA111-(K8).S0
D2301 8-719-073-01 DIODE MA111-(K8).S0
D2302 8-719-073-01 DIODE MA111-(K8).S0
<IC>
IC2001 8-749-015-27 IC MZ1540
IC2101 8-749-013-78 IC MCR5102
IC2201 8-759-388-23 IC TL431BCDR2
IC2202 8-759-388-23 IC TL431BCDR2
IC2301 8-759-998-98 IC LM358D
IC2302 8-759-592-79 IC BA00AST-V5
IC2303 8-759-592-79 IC BA00AST-V5
<COIL>
L2001 1-419-350-11 INDUCTOR 690µH
L2003 ! 1-419-302-11 INDUCTOR 250µH
L2201 1-412-525-31 INDUCTOR 10µH
L2202 1-412-525-31 INDUCTOR 10µH
L2203 1-406-659-11 INDUCTOR 10µH
L2204 1-412-525-31 INDUCTOR 10µH
L2205 1-406-659-11 INDUCTOR 10µH
<PHOTO COUPLER>
PH2101 8-749-010-64 PHOTO COUPLER PC123F2
PH2102 8-749-010-64 PHOTO COUPLER PC123F2
<TRANSISTOR>
Q2001 8-729-119-76 TRANSISTOR 2SA1175-HFE
Q2101 8-729-140-97 TRANSISTOR 2SB734-34
Q2103 8-729-140-97 TRANSISTOR 2SB734-34
Q2201 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2202 8-729-216-22 TRANSISTOR 2SA1162-G
Q2203 8-729-230-49 TRANSISTOR 2SC2712-YG
Q2204 8-729-216-22 TRANSISTOR 2SA1162-G
Q2301 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2302 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2303 1-801-806-11 TRANSISTOR DTC144EKA-T146
Q2304 1-801-806-11 TRANSISTOR DTC144EKA-T146
<RESISTOR>
R2001 1-215-866-11 METAL OXIDE 330 5% 1W F
R2002 1-215-866-11 METAL OXIDE 330 5% 1W F
R2003 ! 1-219-363-11 FUSIBLE 5.6 5% 5W F
R2004 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R2005 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R2006 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2007 1-219-738-11 METAL 0.08 10% 5W
R2101 1-202-933-61 FUSIBLE 0.1 10% 1/2W F
R2102 1-216-345-11 METAL OXIDE 0.47 5% 1W F
R2103 1-216-682-11 METAL CHIP 20K 0.50% 1/10W
R2104 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R2105 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R2106 1-260-135-11 CARBON 1M 5% 1/2W
R2108 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R2109 1-260-135-11 CARBON 1M 5% 1/2W
R2112 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2113 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2116 1-249-389-11 CARBON 4.7 5% 1/4W F
R2117 1-260-135-11 CARBON 1M 5% 1/2W
R2118 1-260-135-11 CARBON 1M 5% 1/2W
R2119 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2120 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2123 1-249-389-11 CARBON 4.7 5% 1/4W F
R2125 1-216-041-00 RES,CHIP 470 5% 1/10W
R2126 1-216-295-91 SHORT 0
R2127 1-216-025-91 RES,CHIP 100 5% 1/10W
R2128 1-216-295-91 SHORT 0
R2130 1-218-759-11 METAL CHIP 200K 0.50% 1/10W
R2131 1-218-759-11 METAL CHIP 200K 0.50% 1/10W
R2132 1-218-759-11 METAL CHIP 200K 0.50% 1/10W
R2133 1-218-759-11 METAL CHIP 200K 0.50% 1/10W
R2134 1-218-759-11 METAL CHIP 200K 0.50% 1/10W
R2135 1-218-759-11 METAL CHIP 200K 0.50% 1/10W
R2136 1-218-760-11 METAL CHIP 220K 0.50% 1/10W
R2201 1-216-295-91 SHORT 0
R2202 1-216-295-91 SHORT 0
R2203 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2204 1-216-295-91 SHORT 0
R2205 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R2206 1-216-041-00 RES,CHIP 470 5% 1/10W
R2207 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R2208 1-216-661-11 METAL CHIP 2.7K 0.50% 1/10W
R2209 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R2210 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2211 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R2212 1-216-687-11 METAL CHIP 33K 0.50% 1/10W
R2213 1-216-049-91 RES,CHIP 1K 5% 1/10W
R2214 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R2215 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2216 1-216-081-00 RES,CHIP 22K 5% 1/10W
R2217 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R2218 1-216-671-11 METAL CHIP 6.8K 0.50% 1/10W
R2219 1-216-097-91 RES,CHIP 100K 5% 1/10W
R2220 1-216-089-91 RES,CHIP 47K 5% 1/10W
R2221 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2301 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2302 1-216-073-00 RES,CHIP 10K 5% 1/10W
R2303 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R2304 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
