Sony VPL-VW10HT Service Manual

6-16
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C5636 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5637 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5690 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5701 1-117-681-11 ELECT CHIP 100µF 20% 16V
C5702 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5703 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5704 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5705 1-117-681-11 ELECT CHIP 100µF 20% 16V
C5706 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5707 1-162-923-11 CERAMIC CHIP 47pF 5% 50V
C5708 1-162-923-11 CERAMIC CHIP 47pF 5% 50V
C5709 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C5710 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C5712 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5713 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5714 1-128-400-11 ELECT CHIP 47µF 20% 25V
C5715 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5716 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5717 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5718 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5719 1-128-400-11 ELECT CHIP 47µF 20% 25V
C5720 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5721 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5722 1-117-681-11 ELECT CHIP 100µF 20% 16V
C5724 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5725 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5726 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5727 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5728 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5729 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C5730 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5731 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5732 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5733 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5736 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5737 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5790 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5801 1-117-681-11 ELECT CHIP 100µF 20% 16V
C5802 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5803 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5804 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5805 1-117-681-11 ELECT CHIP 100µF 20% 16V
C5806 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5807 1-162-923-11 CERAMIC CHIP 47pF 5% 50V
C5808 1-162-923-11 CERAMIC CHIP 47pF 5% 50V
C5809 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C5810 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C5812 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5813 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5814 1-128-400-11 ELECT CHIP 47µF 20% 25V
C5815 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5816 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5817 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5818 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5819 1-128-400-11 ELECT CHIP 47µF 20% 25V
C5820 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5821 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5822 1-117-681-11 ELECT CHIP 100µF 20% 16V
C5824 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5825 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5826 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5827 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5828 1-162-970-11 CERAMIC CHIP 0.01µF 10% 25V
C5829 1-164-156-11 CERAMIC CHIP 0.1µF 25V
C5830 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5831 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5832 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5833 1-107-826-91 CERAMIC CHIP 0.1µF 10% 16V
C5836 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5837 1-128-401-11 ELECT CHIP 100µF 20% 25V
C5890 1-128-401-11 ELECT CHIP 100µF 20% 25V
<CONNECTOR>
CN5001 * 1-785-306-21 CONNECTOR, BOARD TO BOARD 70P
CN5002 * 1-691-591-11 PIN, CONNECTOR (1.5MM) (SMD) 8P
CN5003 * 1-793-798-21 CONNECTOR, BOARD TO BOARD 50P
CN5004 * 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN5005 * 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN5006 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN5007 * 1-580-056-21 PIN, CONNECTOR (SMD) 3P
CN5008 * 1-580-056-21 PIN, CONNECTOR (SMD) 3P
CN5009 * 1-764-007-11 PIN, CONNECTOR (SMD) 12P
CN5010 * 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN5011 * 1-580-055-21 PIN, CONNECTOR (SMD) 2P
CN5201 * 1-785-306-21 CONNECTOR, BOARD TO BOARD 70P
CN5203 * 1-764-177-11 PIN, CONNECTOR (SMD)(1.5MM) 7P
CN5301 1-573-290-21 PIN, CONNECTOR (1.5MM) (SMD) 4P
CN5601 1-793-812-21 CONNECTOR, FFC/FPC 34P
CN5701 1-793-812-21 CONNECTOR, FFC/FPC 34P
CN5801 1-793-812-21 CONNECTOR, FFC/FPC 34P
<DIODE>
D5001 8-719-914-43 DIODE DAN202K
D5002 8-719-914-43 DIODE DAN202K
D5003 8-719-159-10 DIODE RD5.1SB-T2
D5004 8-719-159-10 DIODE RD5.1SB-T2
D5005 8-719-159-10 DIODE RD5.1SB-T2
D5006 8-719-159-10 DIODE RD5.1SB-T2
D5007 8-719-159-10 DIODE RD5.1SB-T2
D5008 8-719-159-10 DIODE RD5.1SB-T2
D5009 8-719-159-10 DIODE RD5.1SB-T2
D5010 8-719-159-10 DIODE RD5.1SB-T2
D5011 8-719-159-10 DIODE RD5.1SB-T2
D5012 8-719-159-10 DIODE RD5.1SB-T2
D5013 8-719-159-10 DIODE RD5.1SB-T2
D5014 8-719-159-10 DIODE RD5.1SB-T2
D5015 8-719-159-10 DIODE RD5.1SB-T2
D5016 8-719-159-10 DIODE RD5.1SB-T2
D5017 8-719-159-10 DIODE RD5.1SB-T2
D5018 8-719-914-43 DIODE DAN202K
D5202 8-719-914-43 DIODE DAN202K
D5301 8-719-914-43 DIODE DAN202K
<FERRITE BEAD>
FB5001 1-414-921-11 INDUCTOR CHIP 0µH
FB5002 1-414-921-11 INDUCTOR CHIP 0µH
FB5003 1-414-921-11 INDUCTOR CHIP 0µH
FB5004 1-414-921-11 INDUCTOR CHIP 0µH
FB5005 1-414-921-11 INDUCTOR CHIP 0µH
FB5006 1-414-921-11 INDUCTOR CHIP 0µH
FB5007 1-414-921-11 INDUCTOR CHIP 0µH
FB5008 1-414-921-11 INDUCTOR CHIP 0µH
FB5009 1-414-921-11 INDUCTOR CHIP 0µH
FB5010 1-414-921-11 INDUCTOR CHIP 0µH
FB5011 1-414-921-11 INDUCTOR CHIP 0µH
FB5012 1-414-921-11 INDUCTOR CHIP 0µH
FB5071 1-414-921-11 INDUCTOR CHIP 0µH
FB5209 1-414-921-11 INDUCTOR CHIP 0µH
FB5210 1-414-921-11 INDUCTOR CHIP 0µH
FB5211 1-414-921-11 INDUCTOR CHIP 0µH
C
