Sony VPL-VW10HT Service Manual

6-17
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
FB5212 1-414-921-11 INDUCTOR CHIP 0µH
FB5261 1-414-921-11 INDUCTOR CHIP 0µH
FB5262 1-414-921-11 INDUCTOR CHIP 0µH
FB5301 1-414-921-11 INDUCTOR CHIP 0µH
FB5302 1-414-921-11 INDUCTOR CHIP 0µH
FB5338 1-414-921-11 INDUCTOR CHIP 0µH
<FILTER>
FL5010 1-239-899-21 FILTER, CHIP EMI
FL5020 1-239-899-21 FILTER, CHIP EMI
FL5030 1-239-899-21 FILTER, CHIP EMI
FL5101 1-234-011-11 FILTER, EMI
FL5102 1-234-011-11 FILTER, EMI
FL5103 1-234-011-11 FILTER, EMI
FL5601 1-234-011-11 FILTER, EMI
FL5602 1-234-011-11 FILTER, EMI
FL5701 1-234-011-11 FILTER, EMI
FL5702 1-234-011-11 FILTER, EMI
FL5801 1-234-011-11 FILTER, EMI
FL5802 1-234-011-11 FILTER, EMI
<IC>
IC5001 8-759-582-91 IC S-80842ANNP-ED6-T2
IC5002 8-759-544-01 IC S-80828ANNP-EDR-T2
IC5003 8-759-058-62 IC TC7S08FU(TE85R)
IC5004 8-759-653-02 IC IRMF
IC5005 8-759-648-10 IC HD64F2633TE
IC5006 8-759-658-90 IC 24LC128T-I/SN
IC5007 8-759-327-60 IC TC7W125FU-TE12R
IC5008 8-759-277-63 IC TC7W14FU(TE12R)
IC5101 8-759-460-72 IC BA033FP-E2
IC5102 8-759-460-72 IC BA033FP-E2
IC5103 8-759-388-31 IC PQ20VZ1U
IC5104 8-759-460-74 IC BA05FP-E2
IC5106 8-759-388-31 IC PQ20VZ1U
IC5107 8-759-460-72 IC BA033FP-E2
IC5108 8-759-645-12 IC AD9884AKS-140
IC5109 8-759-460-81 IC BA12FP-E2
IC5110 8-759-058-62 IC TC7S08FU(TE85R)
IC5120 8-759-598-12 IC LP2985IM5X-3.5
IC5122 8-759-388-31 IC PQ20VZ1U
IC5201 8-759-327-60 IC TC7W125FU-TE12R
IC5204 8-759-544-01 IC S-80828ANNP-EDR-T2
IC5205 8-759-082-57 IC TC7W04FU
IC5206 8-759-475-43 IC TC74LCX125FT(EL)
IC5207 8-759-327-60 IC TC7W125FU-TE12R
IC5208 8-759-664-83 IC MBM29LV400TC-70PFTN-SX1701
IC5209 8-759-645-48 IC IDT71V016S15PH-TL
IC5210 8-759-523-79 IC TC74VHC02FT(EL)
IC5251 8-759-473-33 IC IMISM530AYB-D
IC5252 8-759-646-15 IC ST49C101ACF8-05-TR
IC5301 8-759-491-46 IC TC74VHCT04AFT(EL)
IC5302 8-759-490-41 IC TC74VHCT541AFT(EL)
IC5303 8-759-490-41 IC TC74VHCT541AFT(EL)
IC5304 8-759-592-38 IC CXD9512Q
IC5305 8-759-492-55 IC M24C64-WMN6T
IC5306 8-759-475-43 IC TC74LCX125FT(EL)
IC5307 8-759-649-91 IC W132-10B-E2
IC5308 8-759-544-01 IC S-80828ANNP-EDR-T2
IC5309 8-759-460-72 IC BA033FP-E2
IC5310 8-759-490-41 IC TC74VHCT541AFT(EL)
IC5311 8-759-195-81 IC TC7S86FU
IC5401 8-759-482-47 IC M62399FP-TE2
IC5402 8-759-482-35 IC MC100ELT20DR2
IC5403 8-752-401-90 IC CXD3504R
IC5404 8-759-082-57 IC TC7W04FU
IC5501 8-759-645-13 IC ADV7123KST140
IC5502 8-759-645-13 IC ADV7123KST140
IC5504 8-759-584-86 IC M52749FP-TP
IC5505 8-759-584-86 IC M52749FP-TP
IC5601 8-752-093-18 IC CXA3512R-T6
IC5602 8-752-093-18 IC CXA3512R-T6
IC5701 8-752-093-18 IC CXA3512R-T6
IC5702 8-752-093-18 IC CXA3512R-T6
IC5801 8-752-093-18 IC CXA3512R-T6
IC5802 8-752-093-18 IC CXA3512R-T6
<COIL>
L5001 1-416-606-11 INDUCTOR 47µH
L5101 1-416-606-11 INDUCTOR 47µH
L5102 1-416-606-11 INDUCTOR 47µH
L5103 1-416-606-11 INDUCTOR 47µH
L5104 1-416-606-11 INDUCTOR 47µH
L5105 1-416-606-11 INDUCTOR 47µH
L5106 1-412-030-11 INDUCTOR CHIP 22µH
L5107 1-412-030-11 INDUCTOR CHIP 22µH
L5201 1-412-030-11 INDUCTOR CHIP 22µH
L5202 1-412-030-11 INDUCTOR CHIP 22µH
L5203 1-412-030-11 INDUCTOR CHIP 22µH
L5204 1-412-030-11 INDUCTOR CHIP 22µH
L5301 1-416-606-11 INDUCTOR 47µH
L5302 1-412-030-11 INDUCTOR CHIP 22µH
L5303 1-412-030-11 INDUCTOR CHIP 22µH
L5401 1-469-525-91 INDUCTOR 10µH
L5402 1-469-525-91 INDUCTOR 10µH
L5504 1-469-525-91 INDUCTOR 10µH
L5505 1-469-525-91 INDUCTOR 10µH
L5507 1-469-525-91 INDUCTOR 10µH
L5508 1-469-525-91 INDUCTOR 10µH
L5509 1-469-525-91 INDUCTOR 10µH
L5510 1-469-525-91 INDUCTOR 10µH
L5511 1-469-525-91 INDUCTOR 10µH
L5512 1-469-525-91 INDUCTOR 10µH
L5601 1-469-525-91 INDUCTOR 10µH
L5602 1-469-525-91 INDUCTOR 10µH
L5603 1-216-295-91 SHORT 0
L5604 1-216-295-91 SHORT 0
L5701 1-469-525-91 INDUCTOR 10µH
L5702 1-469-525-91 INDUCTOR 10µH
L5703 1-216-295-91 SHORT 0
L5704 1-216-295-91 SHORT 0
L5801 1-469-525-91 INDUCTOR 10µH
L5802 1-469-525-91 INDUCTOR 10µH
L5803 1-216-295-91 SHORT 0
L5804 1-216-295-91 SHORT 0
<TRANSISTOR>
Q5001 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5002 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q5003 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5004 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5102 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5301 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5302 8-729-026-49 TRANSISTOR 2SA1037AK-T146-R
Q5303 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5304 8-729-230-49 TRANSISTOR 2SC2712-YG
Q5401 8-729-230-49 TRANSISTOR 2SC2712-YG
C
