Sony VPL-VW10HT Service Manual

6-22
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
C
R5852 1-216-789-11 RES,CHIP 2.2 5% 1/16W
R5853 1-216-789-11 RES,CHIP 2.2 5% 1/16W
R5854 1-216-812-11 RES,CHIP 180 5% 1/16W
R5856 1-216-864-11 SHORT 0
R5857 1-216-864-11 SHORT 0
R5858 1-216-864-11 SHORT 0
R5859 1-216-864-11 SHORT 0
R5860 1-216-864-11 SHORT 0
R5861 1-216-864-11 SHORT 0
R5862 1-216-864-11 SHORT 0
R5863 1-216-864-11 SHORT 0
R5864 1-216-864-11 SHORT 0
R5865 1-216-864-11 SHORT 0
R5871 1-216-864-11 SHORT 0
R5872 1-216-864-11 SHORT 0
R5873 1-216-864-11 SHORT 0
R5874 1-216-864-11 SHORT 0
R5875 1-216-864-11 SHORT 0
R5876 1-216-864-11 SHORT 0
R5877 1-216-864-11 SHORT 0
R5878 1-216-864-11 SHORT 0
R5879 1-216-864-11 SHORT 0
R5880 1-216-864-11 SHORT 0
R5881 1-216-864-11 SHORT 0
R5882 1-216-864-11 SHORT 0
R5883 1-216-864-11 SHORT 0
R5884 1-216-864-11 SHORT 0
R5885 1-216-864-11 SHORT 0
R5886 1-216-864-11 SHORT 0
R5895 1-216-864-11 SHORT 0
R5896 1-216-864-11 SHORT 0
<NETWORK>
RB5031 1-233-576-11 RES, CHIP NETWORK 100
RB5032 1-233-576-11 RES, CHIP NETWORK 100
RB5075 1-233-576-11 RES, CHIP NETWORK 100
RB5076 1-233-576-11 RES, CHIP NETWORK 100
RB5101 1-233-576-11 RES, CHIP NETWORK 100
RB5102 1-233-576-11 RES, CHIP NETWORK 100
RB5103 1-233-576-11 RES, CHIP NETWORK 100
RB5104 1-233-576-11 RES, CHIP NETWORK 100
RB5105 1-233-576-11 RES, CHIP NETWORK 100
RB5106 1-233-576-11 RES, CHIP NETWORK 100
RB5107 1-233-576-11 RES, CHIP NETWORK 100
RB5108 1-233-576-11 RES, CHIP NETWORK 100
RB5109 1-233-576-11 RES, CHIP NETWORK 100
RB5110 1-233-576-11 RES, CHIP NETWORK 100
RB5111 1-233-576-11 RES, CHIP NETWORK 100
RB5112 1-233-576-11 RES, CHIP NETWORK 100
RB5213 1-233-574-11 RES, CHIP NETWORK 10
RB5214 1-233-574-11 RES, CHIP NETWORK 10
RB5215 1-233-574-11 RES, CHIP NETWORK 10
RB5216 1-233-574-11 RES, CHIP NETWORK 10
RB5217 1-233-574-11 RES, CHIP NETWORK 10
RB5218 1-233-574-11 RES, CHIP NETWORK 10
RB5219 1-233-574-11 RES, CHIP NETWORK 10
RB5220 1-233-574-11 RES, CHIP NETWORK 10
RB5221 1-233-574-11 RES, CHIP NETWORK 10
RB5222 1-233-574-11 RES, CHIP NETWORK 10
RB5223 1-233-574-11 RES, CHIP NETWORK 10
RB5224 1-233-574-11 RES, CHIP NETWORK 10
RB5301 1-239-409-11 RES, CHIP NETWORK 47
RB5302 1-239-409-11 RES, CHIP NETWORK 47
RB5303 1-239-409-11 RES, CHIP NETWORK 47
RB5305 1-239-409-11 RES, CHIP NETWORK 47
RB5306 1-239-409-11 RES, CHIP NETWORK 47
RB5307 1-239-409-11 RES, CHIP NETWORK 47
RB5308 1-239-409-11 RES, CHIP NETWORK 47
RB5309 1-239-409-11 RES, CHIP NETWORK 47
RB5310 1-239-409-11 RES, CHIP NETWORK 47
RB5311 1-239-409-11 RES, CHIP NETWORK 47
RB5312 1-239-409-11 RES, CHIP NETWORK 47
RB5313 1-239-409-11 RES, CHIP NETWORK 47
RB5314 1-239-409-11 RES, CHIP NETWORK 47
RB5315 1-239-409-11 RES, CHIP NETWORK 47
RB5316 1-239-409-11 RES, CHIP NETWORK 47
RB5317 1-239-409-11 RES, CHIP NETWORK 47
RB5318 1-239-409-11 RES, CHIP NETWORK 47
RB5319 1-239-409-11 RES, CHIP NETWORK 47
RB5320 1-239-409-11 RES, CHIP NETWORK 47
RB5321 1-239-409-11 RES, CHIP NETWORK 47
RB5322 1-239-409-11 RES, CHIP NETWORK 47
RB5323 1-239-409-11 RES, CHIP NETWORK 47
RB5401 1-233-576-11 RES, CHIP NETWORK 100
RB5402 1-239-409-11 RES, CHIP NETWORK 47
RB5403 1-239-409-11 RES, CHIP NETWORK 47
RB5404 1-239-409-11 RES, CHIP NETWORK 47
RB5405 1-239-409-11 RES, CHIP NETWORK 47
RB5406 1-239-409-11 RES, CHIP NETWORK 47
RB5407 1-239-409-11 RES, CHIP NETWORK 47
RB5408 1-239-409-11 RES, CHIP NETWORK 47
RB5409 1-239-409-11 RES, CHIP NETWORK 47
RB5410 1-239-409-11 RES, CHIP NETWORK 47
RB5411 1-239-409-11 RES, CHIP NETWORK 47
RB5412 1-239-409-11 RES, CHIP NETWORK 47
RB5413 1-239-409-11 RES, CHIP NETWORK 47
RB5414 1-233-576-11 RES, CHIP NETWORK 100
RB5601 1-233-574-11 RES, CHIP NETWORK 10
RB5602 1-233-574-11 RES, CHIP NETWORK 10
RB5603 1-233-574-11 RES, CHIP NETWORK 10
RB5604 1-233-574-11 RES, CHIP NETWORK 10
RB5701 1-233-574-11 RES, CHIP NETWORK 10
RB5702 1-233-574-11 RES, CHIP NETWORK 10
RB5703 1-233-574-11 RES, CHIP NETWORK 10
RB5704 1-233-574-11 RES, CHIP NETWORK 10
RB5801 1-233-574-11 RES, CHIP NETWORK 10
RB5802 1-233-574-11 RES, CHIP NETWORK 10
RB5803 1-233-574-11 RES, CHIP NETWORK 10
RB5804 1-233-574-11 RES, CHIP NETWORK 10
<SWITCH>
S5202 1-571-674-11 SWITCH, SLIDE
S5301 1-571-674-11 SWITCH, SLIDE
<THERMISTOR>
TH5001 1-808-656-11 THERMISTOR
<CRYSTAL>
X5063 1-781-659-21 VIBRATOR, CRYSTAL (12.288MHz)
X5201 1-781-774-21 VIBRATOR, CRYSTAL (21.667MHz)
X5202 1-781-354-11 OSCILLATOR, CRYSTAL (80MHz)
*************************************************************
