Sony VPL-VW10HT Service Manual

6-23
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
* 1-675-773-11 PWB, V
**********************
<CONNECTOR>
CN8300 * 1-564-517-11 PLUG, CONNECTOR 2P
<SWITCH>
S8300 1-570-245-11 SWITCH, MICRO (FILTER COVER)
*************************************************************
* 1-675-772-11 PWB, U
**********************
<CONNECTOR>
CN8200 * 1-564-517-11 PLUG, CONNECTOR 2P
<SWITCH>
S8200 1-570-245-11 SWITCH, MICRO (LAMP COVER)
*************************************************************
* A-1375-194-A H COMPL
**********************
<CAPACITOR>
C7001 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C7002 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
<CONNECTOR>
CN7001 * 1-764-007-11 PIN, CONNECTOR (SMD) 12P
<DIODE>
D7001 8-719-045-53 DIODE SEC1801C (LIGHT)
D7002 8-719-045-53 DIODE SEC1801C (PATTERN)
D7003 8-719-045-53 DIODE SEC1801C (RESET)
D7004 8-719-045-61 DIODE SEC1901C (LAMP COVER)
D7005 8-719-045-53 DIODE SEC1801C (LEFT)
D7006 8-719-045-61 DIODE SEC1901C (TEMP/FAN)
D7007 8-719-045-53 DIODE SEC1801C (DOWN)
D7008 8-719-045-53 DIODE SEC1801C (UP)
D7009 8-719-045-53 DIODE SEC1801C (POWER-SAVING)
D7010 8-719-045-53 DIODE SEC1801C (RIGHT)
D7011 8-719-045-60 DIODE SEC1401C (POWER)
D7012 8-719-045-53 DIODE SEC1801C (INPUT)
D7013 8-719-045-53 DIODE SEC1801C (MENU)
D7014 8-719-045-53 DIODE SEC1801C (ENTER)
D7015 8-719-045-51 DIODE SEC2422C (ON/STANDBY)
D7016 8-719-914-43 DIODE DAN202K
D7017 8-719-914-44 DIODE DAP202K
D7018 8-719-914-43 DIODE DAN202K
D7019 8-719-914-44 DIODE DAP202K
D7020 8-719-914-43 DIODE DAN202K
D7021 8-719-914-44 DIODE DAP202K
D7022 8-719-045-53 DIODE SEC1801C (V MEMO)
D7023 8-719-914-43 DIODE DAN202K
D7024 8-719-914-44 DIODE DAP202K
D7025 8-719-045-53 DIODE SEC1801C (LIGHT)
D7026 8-719-045-53 DIODE SEC1801C (LIGHT)
D7027 8-719-045-53 DIODE SEC1801C (MENU)
D7028 8-719-045-53 DIODE SEC1801C (MENU)
D7029 8-719-045-53 DIODE SEC1801C (ENTER)
D7030 8-719-045-53 DIODE SEC1801C (ENTER)
D7031 8-719-045-53 DIODE SEC1801C (RESET)
D7032 8-719-045-53 DIODE SEC1801C (RESET)
D7033 8-719-045-53 DIODE SEC1801C (PATTERN)
D7034 8-719-045-53 DIODE SEC1801C (PATTERN)
<FERRITE BEAD>
FB7001 1-414-235-22 INDUCTOR CHIP 0µH
FB7002 1-414-235-22 INDUCTOR CHIP 0µH
<TRANSISTOR>
Q7001 8-729-230-49 TRANSISTOR 2SC2712-YG
Q7002 8-729-230-49 TRANSISTOR 2SC2712-YG
Q7003 8-729-230-49 TRANSISTOR 2SC2712-YG
Q7004 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q7005 8-729-230-49 TRANSISTOR 2SC2712-YG
Q7006 8-729-230-49 TRANSISTOR 2SC2712-YG
Q7007 8-729-230-49 TRANSISTOR 2SC2712-YG
<RESISTOR>
R7001 1-216-037-00 RES,CHIP 330 5% 1/10W
R7002 1-216-037-00 RES,CHIP 330 5% 1/10W
R7003 1-216-037-00 RES,CHIP 330 5% 1/10W
R7004 1-216-075-00 RES,CHIP 12K 5% 1/10W
R7005 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R7006 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R7007 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R7008 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R7009 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R7010 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R7011 1-216-073-00 RES,CHIP 10K 5% 1/10W
R7012 1-216-037-00 RES,CHIP 330 5% 1/10W
R7013 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R7014 1-216-083-00 RES,CHIP 27K 5% 1/10W
R7015 1-216-037-00 RES,CHIP 330 5% 1/10W
R7016 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R7017 1-216-075-00 RES,CHIP 12K 5% 1/10W
R7018 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R7019 1-216-037-00 RES,CHIP 330 5% 1/10W
R7020 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R7021 1-216-037-00 RES,CHIP 330 5% 1/10W
R7022 1-216-037-00 RES,CHIP 330 5% 1/10W
R7023 1-216-037-00 RES,CHIP 330 5% 1/10W
R7024 1-216-037-00 RES,CHIP 330 5% 1/10W
R7025 1-216-037-00 RES,CHIP 330 5% 1/10W
R7026 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R7027 1-216-037-00 RES,CHIP 330 5% 1/10W
R7028 1-216-055-00 RES,CHIP 1.8K 5% 1/10W
R7029 1-216-053-00 RES,CHIP 1.5K 5% 1/10W
R7030 1-216-057-00 RES,CHIP 2.2K 5% 1/10W
R7031 1-216-059-00 RES,CHIP 2.7K 5% 1/10W
R7032 1-216-049-91 RES,CHIP 1K 5% 1/10W
R7033 1-216-073-00 RES,CHIP 10K 5% 1/10W
R7034 1-216-037-00 RES,CHIP 330 5% 1/10W
R7035 1-216-037-00 RES,CHIP 330 5% 1/10W
R7036 1-216-037-00 RES,CHIP 330 5% 1/10W
R7038 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R7039 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
V U H
