Sony VPL-VW10HT Service Manual

6-24
VPL-VW10HT
Ref.No. Part No. Description RemarkRef.No. Part No. Description Remark
R7040 1-216-037-00 RES,CHIP 330 5% 1/10W
R7041 1-216-037-00 RES,CHIP 330 5% 1/10W
R7042 1-216-037-00 RES,CHIP 330 5% 1/10W
R7043 1-216-037-00 RES,CHIP 330 5% 1/10W
R7044 1-216-037-00 RES,CHIP 330 5% 1/10W
R7045 1-216-037-00 RES,CHIP 330 5% 1/10W
R7046 1-216-061-00 RES,CHIP 3.3K 5% 1/10W
R7047 1-216-037-00 RES,CHIP 330 5% 1/10W
R7048 1-216-037-00 RES,CHIP 330 5% 1/10W
<SWITCH>
S7001 1-771-105-11 SWITCH, TACTILE (LIGHT)
S7002 1-771-105-11 SWITCH, TACTILE (PATTERN)
S7003 1-771-105-11 SWITCH, TACTILE (RESET)
S7004 1-771-105-11 SWITCH, TACTILE (LEFT)
S7005 1-771-105-11 SWITCH, TACTILE (UP)
S7006 1-771-105-11 SWITCH, TACTILE (DOWN)
S7007 1-771-105-11 SWITCH, TACTILE (RIGHT)
S7008 1-771-105-11 SWITCH, TACTILE (POWER)
S7009 1-771-105-11 SWITCH, TACTILE (INPUT)
S7010 1-771-105-11 SWITCH, TACTILE (MENU)
S7011 1-771-105-11 SWITCH, TACTILE (ENTER)
S7012 1-771-105-11 SWITCH, TACTILE (V MEMO)
*************************************************************
* 1-675-776-11 PWB, NF
**********************
<CAPACITOR>
C8000 1-124-589-11 ELECT 47µF 20% 10V
<CONNECTOR>
CN8000 * 1-564-518-11 PLUG, CONNECTOR 3P
<IC>
IC8000 8-749-011-03 IC GP1U26X
<RESISTOR>
R8000 1-216-017-91 RES,CHIP 47 5% 1/10W
R8001 1-216-025-91 RES,CHIP 100 5% 1/10W
*************************************************************
* 1-675-771-11 PWB, NR
**********************
<CAPACITOR>
C8100 1-124-589-11 ELECT 47µF 20% 10V
<CONNECTOR>
CN8100 * 1-564-518-11 PLUG, CONNECTOR 3P
<IC>
IC8100 8-749-011-03 IC GP1U26X
NF NR TH
<RESISTOR>
R8100 1-216-017-91 RES,CHIP 47 5% 1/10W
R8101 1-216-025-91 RES,CHIP 100 5% 1/10W
*************************************************************
* 1-675-920-11 PWB, TH
**********************
<CONNECTOR>
CN8400 * 1-580-057-11 PIN, CONNECTOR (SMD) 4P
<THERMISTOR>
TH8400 1-806-656-11 THERMISTOR
*************************************************************
MISCELLANEOUS
**********************
1-758-451-11 OPTICAL UNIT
! 1-526-813-12 INLET, AC (3P) (100-240V)
1-698-059-11 FAN, DC
1-763-070-11 FAN, DC
1-763-417-11 FAN, DC
1-900-222-47 CONNECTOR ASSY 2P
*************************************************************
ACCESSORY
**********************
! 1-534-827-14 CORD, POWER (7A/125V)
! 1-777-649-11 CORD, POWER (10A/250V)
! 1-782-929-11 CORD, POWER SUPPLY(BS 3P)
(10A/250V)
1-418-834-11 REMOTE COMMANDER(RM-PJVW10)
3-704-356-01 SHEET (STANDARD), PROTECTION
4-074-835-11 MANUAL, INSTRUCTION
(ENGLISH, FRENCH, SPANISH)
4-074-835-21 MANUAL, INSTRUCTION
(GERMAN, ITALIAN)
4-074-850-01 FILTER
4-074-906-01 BOX, ACCESSORY
9-885-000-82 BATTERY COVER (FOR RM-PJVW10)
H
