Soredex CRANEX Novus e - Replacing the CCD Sensor; Replacing the Collimator; Replacing Circuit Boards; L900 Display Adaptor - Additional Instructions

96 Service manual
7. Replacing parts CRANEX
®
Novus e
7.3 Replacing the CCD sensor
After replacing the CCD sensor, realign the unit (refer to
section 8. Aligning the unit).
7.4 Replacing the collimator
After replacing the collimator, realign the unit (refer to
section 8. Aligning the unit).
7.5 Replacing circuit boards
1. Switch the unit off and disconnect it from the
power supply.
2. Remove the appropriate cover(s) so that you
can access the circuit board you wish to re-
place.
3. Disconnect all the cables from the circuit
board, remove the board and install the new
one.
L900 Display adaptor - additional instructions
After replacing L900 and display assembly (rev 6 and
later) check that the jumpers on the board are in the
correct positions for the touch display installed in the
unit.
For touch display:
- OPTREX T-55265GD057J-LW-ACN
SW1 = on, SW2 = on
For touch display:
- SHARP LQ057Q3DG01
SW1 = off, SW2 = on
NOTE:
When L900 and display assemblies are ordered as
spareparts, they are always preset and tested at the
factory.
The switch information is just for your information.
