Novus e 3. Circuit Boards - L1500, CCD Power Supply
Service manual 35
L1500 - Indicator LEDs
LED Colour Indicates
D8 green +15V_CCD on
D9 green +3.0V_CCD on
D10 green +3.3V_CCD on
D12 green +5V on
D13 green +5.0V_CCD on
D14 green -9.4V_CCD on
D16 green +24V on
D17 green +3.3V on
L1500 - Test Points
Number Description Value
TP1 +24V +24V
TP5 CCDENA 5V on, 0V off
TP7 +5.0V
TP8 +5.0V_CCD
TP10 +3.3V
TP11 +3.0V_CCD
TP12 +15V
TP15 U_IN Between 1.3V and 3.5V
TP18 -9.4V_CCD
TP25 GND (logic) 0V
TP40 +3.3V_CCD
TP65 GND (logic) 0V
TP65 GND (logic) 0V
