Heater-Cooler System 3T • Installation
CP_IFU_16-XX-XX_USA_015 4.7
Opening/closing the venting valves
Fig. 8: Opening/closing the venting valves
For operating the heater-cooler, the venting valves have to be opened (position A).
For emptying the tubing system, the venting valves have to be closed (position B).
Disconnecting the tubings
Fig. 9: Disconnecting the tubings
To disconnect a tubing from the heater-cooler:
◗ Empty the tubing system.
◗ Disconnect the tubing, push the locking ring of the Hansen connector toward the back panel of the
base unit.
◗ Gently pull off the tubing.
