Heater-Cooler System 3T • Installation
CP_IFU_16-XX-XX_USA_015 4.5
Connecting the overflow tube
Fig. 6: Connecting the overflow tube
◗ Hang the overflow bottle 14 with its holder on the ventilation grill at the rear of the heater-cooler.
◗ Connect a 1/2" tubing to the overflow outlet 13.
◗ Insert the other end of the tubing into the lid of the bottle 14 to collect excess water (during filling).
