Scorpio User Guide
35
RF HISTORY DURATION Sets the duration of the RF HISTORY plot.
Select from 30 to 600 seconds in 10 second steps, default duration
is 30 seconds.
USE WIRELESS NAMES When On the name associated with the re-
ceiver channel is automatically applied to the isolated track receiving
the signal. This feature is supported by the Audio Ltd. A10-RX and the
Shure ADX5D.
SL-6
When combined with Scorpio, the SL-6 offers easy integration of mul-
tiple channels of wireless connectivity, mixing, recording and power
management in a lightweight and easy to use package. The SL-6
simplies interconnection between the Scorpio and multiple channels
of wireless by accepting three dual-channel slot-in receivers provid-
ing a total of six separate audio feeds. Easily attaching to Scorpio’s
top panel, the SL-6 offers all powering and audio interconnection for
standard slot-in receivers and additional control and monitoring when
used with SuperSlot compatible receivers. The SL-6 also distributes
RF from external antennas to the receivers, creating a more efcient,
compact conguration.
The SL-Riser accessory is required for connection of the SL-6 to
Scorpio. See the SL-Riser installation instructions here:
https://www.
sounddevices.com/sl-riser-assembly/
The Scorpio must be powered via the SL-6 DC or NP-1 power source
to use the SL-6.
WARNING! Remove all batteries and disconnect DC inputs from both
the SL-6 and Scorpio prior to connecting the SL-6 to the Scorpio. Fail-
ure to remove power could result in damage to the hardware.
Supported SuperSlot receivers for use in the SL-6 are:
• Audio Ltd. A10-RX
• Lectrosonics SRb, SRc, SRc-941, SRb5P (Slot B or C only), SRc5P
(Slot B or C only)
• Sennheiser EK6042 (does not support scan)
• Shure ADX5D
• Sony DWR-S03D
• Wisycom MCR42
• Wisycom MCR54 (2 channels per receiver only)
