Spark L50 - Specifications

Specifications
37
Specifications
1. L50 Specifications
DIMENSIONS
Length
1030 mm | 40.6 in
Width
580 mm | 22.8 in
Height (main body)
1045 mm | 41.1 in
Weight
220 Kg | 485 lbs
GVW
275 Kg | 606 lbs
Cleaning Width
510 mm | 20 in
Squeegee Width
800 mm | 31.5 in
CLEANING
Max. Theoretical Productivity (regular cleaning)
2570 m²/hr | 27663 ft²/hr
Brush Pressure
25 Kg
Disk Brush Speed
220 RPM
Solution Tank Capacity
55 L | 14.5 gal
Recovery Tank Capacity
55 L | 14.5 gal
MOVEMENT
Max. Speed
1.4 m/s | 3.13 mph
Min. Distance from Wall
<50 mm | 2 in
Min. Passable Width
900 mm | 35.4 in
Gradeability
10% (The machine is not
recommended for running on slopes
in automatic mode, and it can be
operated manually on slopes ≤10%.)
POWER
Battery Type
Lithium Iron Phosphate
Battery Capacity
120 Ah
Rated Voltage
24 VDC
Charging Time
4 hours
Max. Runtime
6 hours
SENSING
3D LiDAR, 3D Depth Camera,
Ultrasonic Sensor, Bumper Sensor
SOUND PRESSURE LEVEL
At least as 67 dB（A）
VIBRATION AT THE HANDLE
＜2.5 m/s²
