ADDITIONAL SERVICE PARTS & GUIDE TUBES
PART NAME NUMBER PART SPECIFICATION PART DESCRIPTION QTY
Chainstay Alloy (Satin Black)
S211500002
CS,MTB,PA TRAIL FSR F1.1,ALY 1
Bearing 12 mm ID x 24 mm OD x 6 mm W,DBL SLD BRG,BALL,12mm ID X 24mm OD X 6mm W,DBL SLD  2
Chainstay Carbon (Gloss Carbon)
S211500003
CS,MTB,PA TRAIL FSR F1.2  1
Bearing 12 mm ID x 24 mm OD x 6 mm W,DBL SLD BRG,BALL,12mm ID X 24mm OD X 6mm W,DBL SLD  2
Seatstay Alloy (Satin Black)
S215000002 STS MY22 LEVO ALLOY, STN BLK
Seatstay SS,MTB,PA TRAIL FSR F1.1,ALY 1
Bearing Horst 12 mm ID x 21 mm OD x 5 mm W DBL SLD  BRG,BALL,12mm ID X 21mm OD X 5mm W,DBL SLD  4
Bearing Spacer 12.1mm ID x 23 mm OD x 3 mm W SPCR,CUST, 12.1 ID X 23 OD X 3 W,FSR,AL7075-T73  2
Seatstay Carbon (Gloss Carbon)
S215000003
STS MY22 LEVO CARBON, GLS BLK
Seatstay SS,MTB,PA TRAIL FSR F1.2,CRBN  1
Bearing Horst 12 mm ID x 21 mm OD x 5 mm W DBL SLD  BRG,BALL,12mm ID X 21mm OD X 5mm W,DBL SLD  4
Bearing Spacer 12.1mm ID x 23 mm OD x 3 mm W SPCR,CUST, 12.1 ID X 23 OD X 3 W,FSR,AL7075-T73  2
Bearing Suspension Kit
S210600002 BRG MY22 LEVO SUSPENSION BEARING KIT
Bearings 12 mm ID x 21 mm OD x 5 mm W,DBL SLD  BRG,BALL,12mm ID X 21mm OD X 5mm W,DBL SLD  12
Bearing - Main Pivot 12 mm ID x 24 mm OD x 6 mm W,DBL SLD  BRG,BALL,12mm ID X 24mm OD X 6mm W,DBL SLD  2
Shock Link
S214300006
SHL MY22 LEVO SHOCK LINK ASSEMBLY
Right Link LINK,PA TRAIL FSR F1,ALY,RIGHT  1
Left Link LINK,PA TRAIL FSR F1,ALY,LEFT  1
Bearings 12 mm ID x 21 mm OD x 5 mm W,DBL SLD BRG,BALL,12mm ID X 21mm OD X 5mm W,DBL SLD  8
Bearing Spacer 12 mm ID x 18 mm OD x 2 mm W  SPCR,12mm ID X 18mm OD X 2mm W,7075-T6  2
Shock Extension
S216300003
SHK EXT MY22 LEVO SHOCK EXTENSION
Extension 96.5 mm 96.5 mm LENGTH, ALLOY  EXTN,PA TRAIL FSR F1,96.5mm LENGTH,ALLOY 
Suspension Bolt Kit
S210500012
BLT MY22 LEVO SUSPENSION BOLT KIT
Horst Pivot Outer Bearing Spacer 12 mm ID x 21 mm OD x 2.5 mm W HORST PIVOT OUTER SPACER ASSY 12X21X2.5  4
Link @ Seat Tube Bearing Spacer 12.1 mm ID x 19.5 mm OD x 3 mm W SPCR,12.1 ID X 19.5 OD X 3 W,FSR,AL7075-T6  2
Speed Sensor Retaining Bolt M4 x 14 mm x 0.7 mm p SCR,SKT FLT HD,M4X0.7 X 14,7075-T73,BLK  1
Link @ Seatstay Bolt Female M6 x 22.34 mm x 1 mm p FEM  BOLT,CUST,M6 X1FEM X 22.34,7075,BLK  2
Horst Flip Chip Outer DO PIVOT SPACER,GEO ADJ,6.0 ID, FLAT  2
Horst Flip Chip Inner DO PIVOT SPACER,GEO ADJ,M6 X 1  2
Horst Pivot Inner Bearing Spacer 6 mm ID x 16 mm OD x 16 mm W SPCR,STEP,6mm ID X 16mm OD X 16mm W,7075-T6  2
Horst Pivot Bolt M6 x 32.5 mm x 1.0 mm p SCR,CUST,M6X1.0 X 32.5,STL,BLK  2
Link @ Seat Tube Bolt M12 x 24 mm x 1.0 p SCR ASSY,M12 X 1.0 X 24,PA TRAIL FSR F1  2
Link Spacers 10 mm ID x 18.5 mm OD x 2.5 mm W
SPCR,CUST, 10 ID X 18.5 OD X 2.5 W,FSR,AL7075-T73 
8
Link @ Extension Axle AXLE,SS PIVOT,MTB,TRAIL FSR L1  2
Link @ Seat Stay Bolt Male M6 x 8 mm x 1.0 mm p S-Steel  SCR,CUST,M6X1.0 X 8,SST 302  4
Main Pivot Bolt RHT M10 x 35 mm x 1.25 mm p, RH, S-Steel SCR,CUST,M10 X 1.25 X 35,RH,SST 302  1
Main Pivot Spacer 12.1 mm ID x 23 mm OD x 3 mm W SPCR,CUST, 12.1 ID X 23 OD X 3 W,FSR,AL7075-T73  2
Main Pivot Sleeve 10 mm ID x 21 mm OD x 3 mm W, S-Steel SLEEVE,CUST,10 ID X 21 OD X 3 W,SST 302  2
Main Pivot Washer 10.6 mm ID x 21 mm OD x 0.5 mm S-Steel WSHR,10.6 ID X 21 OD X 0.5 THK,304 SST  2
Main Pivot Bolt LHT M10 mm x 35 mm x 1.25 mm p,LH, S-Steel SCR,CUST,M10 X 1.25 X 35,LH,SST 302 1
Rear Shock Mounting Hardware
S210500011
BLT MY22 LEVO REAR SHOCK MOUNTING HARDWARE KIT
Rear Shock Mountning Washer M8 x 8.3 ID X 13 OD X 0.5 mm S-Steel WSHR,FLAT,M8,8.31DXl3ODX0.5THK,304SST 1
Rear Shock Mountning Bolt M8 x 27 mm x I .25 mm,CHOMOLY SCR,CUST,M8XI .25 X 27,CHOMOLY 1
Shock Eyelet Spacers 19 mm X 8.1 mm X 0.6 mm,S-Steel SPACER.SHOCK, 19X8. IX0.6,SST 304 2
Froward Shock Mountning Bolt M8 x 42 mm x I.0 mm p SCR,CUST,M8XI .0 X 42,STL,BLK,LCK 1
SRAM Universal Derailler Hanger
S202600002 HGR SRAM AC UDH DERAILLEUR HANGER AL BLACK 1
Alloy Frame side arm cover
S226500007
Plastic Sidearm Cover
1
