LOCATION TOOL
TORQUE
Nm in-lbf
SEAT COLLAR 4 mm hex 6.2 55
STEM @ STEERER TUBE(TRAIL STEM) 5 mm hex 8 71
STEM @ HANDLEBAR(TRAIL STEM) 5 mm hex 6 53
SPIDER LOCK-RING
Shimano BB-UN 98 / Park Tool
BBT-18
50 443
CRANK BOLTS 8 mm hex 40 354
CHAINRING BOLTS 5 mm hex 10 89
WATER BOTTLE CAGE BOLT 3 mm hex 2.8 25
12 mm REAR AXLE 6 mm hex 15 133
DERAILLEUR HANGER 8 mm hex 25 221
HEAD TUBE ICR GUIDE SCREW T10 Torx 0.8 7
TCU DISPLAY 1 & 2 T10 Torx 0.8 7
MOTOR MOUNT BOLTS REAR T30 Torx 18 160
MOTOR MOUNT BOLTS CENTER T30 Torx 18 160
MOTOR MOUNT BOLT FRONT DS T25 Torx 6 53
MOTOR MOUNT BOLT FRONT NDS T30 Torx 6 53
MOTOR COVER BOLTS DRIVE SIDE 2.5 mm hex 2 18
MOTOR COVER BOLTS NON DRIVE SIDE 3 mm hex 1 9
SPEED SENSOR BOLT ( @HORST PIVOT) 3 mm hex 1 9
SPEED SENSOR MAGNET HOLDER (6 BOLT VERSION) T25 Torx 6.2 55
REMOTE 2 mm hex 0.8 7
BATTERY BOLT 6 mm hex 6.2 177
BATTERY ROCK GUARD THRU-BOLT 4 mm hex 3 26
BATTERY EXPANDER BOLT 4 mm hex 4 35
BATTERY ROCK GUARD BOLTS 2.5 mm hex 0.8 7
REAR BRAKE GUIDE (NON-DRIVE SIDE SEATSTAY) 2.5 mm hex 0.8 7
MAIN HARNESS CLAMP 2.5 mm hex 4 35
MUD FLAP BOLTS 2.5 mm hex 4 35
MOTOR HOUSING CABLE GUIDE BOLTS 2.5 mm hex 4 35
CHAIN GUIDE 5 mm hex 4.5 40
ALLOY FRAME SIDE ARM COVER 3 mm hex 1 9
LOCATION TOOL
TORQUE
Nm
in-lbf
MAIN PIVOT (DS - LEFT HAND THREAD)
6 mm 210 24
LINK @ SEAT-TUBE
6 mm 185 21
LINK @ SEAT-STAY
4/6 mm 70 8
LINK @ EXTENSION
4/5 mm 70 8
DROPOUT (HORST LINK)
5 mm 90 10
FORWARD SHOCK EYE
6 mm 90 10
REAR SHOCK EYE
5 mm 185 21
2022 LEVO F1 CARBON NYLON TUBE LENGTH
SIZE SHIFT (mm) BRAKES (mm) DROPPER POST (mm)
S1 1070 925 385
S2 1105 960 395
S3 1125 980 410
S4 1145 1000 430
S5 1190 1045 465
S6 1205 1060 480
2022 LEVO F1 ALLOY NYLON TUBE LENGTH
SIZE SHIFT (mm) BRAKES (mm) DROPPER POST (mm)
S1 780 660 385
S2 780 660 395
S3 780 660 410
S4 780 660 430
S5 780 660 465
S6 780 660 460
BRAKE ROTOR
Max Min Info
Brake rotor rear 220 mm 180 mm Post mount standard
CHAINRING
Max Min Info
Chainring 34 T 32 T 36 T can be used without the chain guide
SEATPOST
SIZE MAX INSERTION MIN INSERTION
S1 210 mm
100 mm
S2 220 mm
S3 240 mm
S4 260 mm
S5 280 mm
S6 295 mm
TORQUE SPECIFICATIONS & GUIDE TUBE LENGHTHS
PAGE 39
2022
TECHNICAL GUIDE
