both values are highlighted and will adjust simultaneously. Moving the stick or switch in the
desired position adjusts that direction of travel independently. With the desired value(s)
highlighted, rotate the roller to adjust the travel for the selected channel. Then press to
accept.
Airpl
ane
Mode
l
Servo
Setup
page 22
D/R
and
Expone
ntial
page 23
Differen
tial
page 24
Throttle
Cut
page 25
Throttle
Curve
page 25
Flap
System page
26 M
«
ng
page 29
Aileron to
Rudder
Program
mable
Mix
Timer
page 33
Mo
SERVO SETUP
Helicopter Model
Servo Setup page 22 D/R and Exponential
page 23 Throttle Cut
IMFilK
To Access the Sub Trim Function
With the transmitter on and the main or
telemetry screen up, press the roller. The
Function list displays. Rotate the roller to
highlight Servo Setup then press. Servo
travel will automatically be highlighted.
Rotate the roller until Sub-Trim appears in
the channel position then press to enter the
function.
Highlight the value at the bottom of the
screen then press the roller to access the
Sub- Trim Value. Rotate the roller to adjust
the Sub-Trim value for the selected
channel. Then press to accept.
FUNCTION
MODE
r page 35
Differential
The DX8 organizes the programming screens in two separate categories: System Setup Mode
and Functions Mode. Function Mode programming adjusts a model's flight characteristics at
the field.
page 25 Throttle Curve page 26
Swashplate page 27 Governor page
28 Pitch Curve page 28 Tail Curve-
For Non-Heading Hold Gyro Use Only
page 30 Mixing page 31 Gyro page
33 Timer page 33 Monitor page 35
To Access the Function List
With the transmitter on and the main or telemetry screen displayed, press the roller. The
Function list displays.
To Access a Function List Screen from the Function List
Highlight the desired function then press the roller to access that function. The selected
function screen appears:
12 SPEKTRUM DX8 • RADIO INSTRUCTION MANUAL
