SPX S2045 - Page 16

Table 4: Table of Dimensions for Figure 6, page 15
Frame
A
inch
(mm)
O
inch
(mm)
D
inch
(mm)
F
inch
(mm)
AB
inch
(mm)
145JM 9.32 (237) 7.1 (180) 3.5 (89) 0.88 (22) 5.73 (145)
182JM 9.32 (237) 8.1 (206) 4.5 (114) 0.88 (22) 5.73 (145)
184JM 11.11 (282) 8.49 (216) 4.5 (114) 1.09 (28) 6.87 (174)
213JM 13.18 (335) 10.39 (264) 5.25 (133) 1.38 (35) 8.04 (204)
215JM 13.18 (335) 10.39 (264) 5.25 (133) 1.38 (35) 8.04 (204)
254JM 15.34 (390) 11.39 (289) 6.25 (159) 1.38 (35) 9.40 (239)
256JM 15.34 (390) 11.39 (289) 6.25 (159) 1.38 (35) 9.40 (239)
284JM 20.78 (528) 14.44 (367) 7.0 (178) 2.0 (51) 13.12 (333)
286JM 20.49 (520) 14.44 (367) 7.0 (178) 2.0 (51) 13.12 (333)
324JM 23.05 (585) 16.25 (413) 8.0 (203) 2.5 (63) 14.61 (371)
326JM 23.05 (585) 16.25 (413) 8.0 (203) 2.5 (63) 14.61 (371)
Introduction Waukesha Cherry-Burrell
Page 16 95-03080 12/2010
NOTE: Figure 6 dimensions for the Inlet, Outlet, items X,Y, and Z are listed in Table 7 on page 17.
Table 5: Table of Dimensions for Figure 6, page 15
FRAME
PUMP SIZE
S2045 S2065 S2065LV S2065HV
LP CP LP CP LP CP LP CP
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
145JM 2.92 (74) 18.18 (461) 2.71 (69) 18.43 (468) 2.71 (69) 17.93 (455) 2.71 (69) 18.85 (479)
182JM 2.92 (74) 19.56 (497) 2.71 (69) 19.81 (503) 2.71 (69) 19.31 (490) 2.71 (69) 20.23 (514)
184JM 2.92 (74) 20.81 (529) 2.71 (69) 21.01 (534) 2.71 (69) 20.56 (522) 2.71 (69) 21.43 (544)
213JM -- -- 2.97 (75) 22.81 (579) 2.97 (75) 22.31 (567) 2.97 (75) 23.23 (590)
215JM -- -- 2.97 (75) 23.94 (608) 2.97 (75) 23.44 (595) 2.97 (75) 24.36 (618)
254JM -- -- 3.97 (101) 26.07 (662) 3.97 (101) 25.57 (649) 3.97 (101) 26.49 (673)
256JM -- -- 3.97 (101) 27.83 (707) 3.97 (101) 27.33 (694) 3.97 (101) 28.25 (718)
284JM -- -- 3.97 (101) 31.43 (798) 3.97 (101) 30.93 (786) 3.97 (101) 31.85 (809)
286JM -- -- 3.97 (101) 31.64 (804) 3.97 (101) 31.14 (791) 3.97 (101) 32.06 (814)
324JM -- -- -- -- -- -- -- --
326JM -- -- -- -- -- -- -- --
