SPX S2045 - Page 17

Table 6: Table of Dimensions for Figure 6, page 15
Frame
Pump Size
S2075 S2085 S2085LV S2092
LP CP LP CP LP CP LP CP
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
Inches
(mm)
145JM 2.75 (70) 18.17 (461) 2.75 (70) 18.84 (478) 2.75 (70) 18.17 (461) 2.75 (70) 18.78 (477)
182JM 2.75 (70) 19.55 (497) 2.75 (70) 21.21 (513) 2.75 (70) 19.55 (497) 2.75 (70) 20.16 (512)
184JM 2.75 (70) 20.80 (528) 2.75 (70) 21.46 (545) 2.75 (70) 20.80 (528) 2.75 (70) 21.41 (544)
213JM 2.84 (72) 22.39 (569) 2.84 (72) 23.06 (586) 2.84 (72) 22.39 (569) 2.84 (72) 23.00 (584)
215JM 2.84 (72) 23.52 (597) 2.84 (72) 24.19 (614) 2.84 (72) 23.52 (597) 2.84 (72) 24.13 (613)
254JM 3.84 (98) 25.65 (651) 3.84 (98) 26.32 (668) 3.84 (98) 25.65 (651) 3.84 (98) 26.26 (667)
256JM 3.84 (98) 27.41 (696) 3.84 (98) 28.08 (713) 3.84 (98) 27.41 (696) 3.84 (98) 28.02 (712)
284JM 3.84 (98) 31.01 (788) 3.84 (98) 31.68 (805) 3.84 (98) 31.01 (788) 3.84 (98) 31.62 (803)
286JM 3.84 (98) 31.22 (793) 3.84 (98) 31.89 (810) 3.84 (98) 31.22 (793) 3.84 (98) 31.83 (808)
324JM 3.84 (98) 33.11 (841) 3.84 (98) 33.78 (858) 3.84 (98) 33.11 (841) -- --
326JM 3.84 (98) 33.11 (841) 3.84 (98) 33.78 (858) 3.84 (98) 33.11 (841) -- --
Table 7: Table of Dimensions for Figure 6, page 15
Model
Inlet
inch (mm)
Outlet
inch (mm)
X
inch (mm)
Y
inch (mm)
Z
inch (mm)
MP
inch (mm)
S2045
1.5 (38) 1.5 (38) 3.88 (99) 2.56 (65) 1.99 (51) 4.08 (104)
2.0 (51) 1.5 (40) 3.88 (99) 2.56 (65) 1.99 (51) 4.08 (104)
S2065 2.5 (64) 2.0 (51) 4.94 (125) 2.68 (68) 2.88 (73) 4.53 (115)
S2065LV
1.5 (38) 1.5 (38) 4.94 (125) 2.43 (62) 3.13 (79) 4.03 (102)
2.0 (51) 1.5 (38) 4.94 (125) 2.43 (62) 3.13 (79) 4.03 (102)
2.5 (64) 1.5 (38) 4.94 (125) 2.43 (62) 3.13 (79) 4.03 (102)
S2065HV 3.0 (76) 2.0 (51) 4.94 (125) 3.04 (77) 2.88 (73) 4.96 (126)
S2075 3.0 (76) 1.5 (40) 6.69 (170) 2.70 (69) 4.32 (110) 4.24 (108)
S2085
3.0 (76) 2.5 (64) 5.75 (146) 2.93 (74) 3.82 (97) 4.91 (125)
4.0 (102) 2.5 (64) 5.75 (146) 2.93 (74) 3.82 (97) 4.91 (125)
S2085LV 2.0 (51) 1.5 (40) 6.69 (170) 2.70 (69) 4.32 (110) 4.24 (108)
S2092 3.0 (76) 2.0 (51) 6.64 (169) 3.09 (78) 4.62 (117) 4.85 (123)
Waukesha Cherry-Burrell Introduction
12/2010 95-03080 Page 17
