SPX W Series User Manual

Item # 1-1/2" 2" 2-1/2" 3" 4" 6"
1 Control Top
3 Actuator
*
4 O-ring Nitrile
N70010 N70010 N70111 N70111 N70111 N70111
*
5 Bearing
102757+ 102757+ 106047+ 106047+ 106047+ 101995+
6 O-ring, Body (qty 4 req) EPDM
E70223 E70228 E70232 E70236 E70244 E70258
FKM
V70223 V70228 V70232 V70236 V70244 V70258
8 Stem, Upper Assembly - See note 1, below
10a Seat Ring -Tri Ring, Upper EPDM
106031+ 102736+ 107048+ 102488+ 102491+ 102738+
FKM
107990+ 107980+ 107982+ 107974+ 107977+ 108020+
11 Seat Ring -Tri Ring, Vent EPDM
106041+ 107693+ 107696+ 107697+ 102490+ 102737+
FKM
107992+ 107984+ 107987+ 107988+ 107976+ 108019+
12a Seat Ring -Tri Ring, Lower EPDM
106036+ 107693+ 102487+ 102489+ 102492+ 102739+
FKM
107991+ 107984+ 107973+ 107975+ 107978+ 108021+
O-ring, Lower Stem EPDM
E70322 E70327 E70331 E70335 E70342 N/A
FKM
V70322 V70327 V70331 V70335 V70342 N/A
Quad Ring, Lower EPDM
122690+ 35413+ 117992+ 117561+ 116952+ 122350+
FKM
122689+ 35414+ 117993+ 117562+ 116953+ 122351+
* 14b
Wiping Stem Seal, Lower EPDM
116186+ 116188+ 116190+ 116195+ 116199+ POA
FKM
116187+ 116189+ 116191+ 116196+ 116200+ POA
*
15 Bearing
101947+ 102000+ 106049+ 106048+ 102003+ 102004+
16
17a Seal Retainer, O-ring or Quad Ring 106066+ 106067+ 106068+ 106069+ 106070+ 125047+
17b Seal Retainer, Wiping Stem Seal 117444+ 117445+ 117446+ 117447+ 117448+ POA
17c Seal Retainer, Lower Flush, O-ring or Quad Ring 114918+ 114919+ 114920+ 114921+ 114922+ POA
17d Seal Retainer, Lower Flush, Wiping Stem Seal 119050+ 119035+ 118226+ 117559+ 118253+ POA
18 Clamp 119-30 119-33 119-34 119-51 119-87 119-123
19 Spray Bushing 106030+ 106030+ 107950+ 107950+ 107950+ 107950+
20a Adapter, O-ring or Quad Ring 106020+ 106021+ 106022+ 106023+ 106024+ 128651+
20b Adapter, Wiping Stem Seal 119482+ 119483+ 119484+ 119485+ 119486+ POA
O-ring, Upper Stem EPDM
E70210 E70210 E70214 E70214 E70214 N/A
FKM
V70210 V70210 V70214 V70214 V70214 N/A
Quad Ring, Upper (qty 3 required) EPDM
121300+ 121300+ 124163+ 124163+ 124163+ 114221+
FKM
124088+ 124088+ 121299+ 121299+ 121299+ 114223+
* 21b
Wiping Stem Seal, Upper EPDM
116183+ 116183+ 116184+ 116184+ 116184+ POA
FKM
115626+ 115626+ 116185+ 116185+ 116185+ POA
25 O-ring EPDM
E70010 E70010 E70111 E70111 E70111 E70111
FKM
V70010 V70010 V70111 V70111 V70111 V70111
*
26 O-ring (qty 2 required) Nitrile
N90016 N90016 N90020 N90020 N90020 N90020
37 Stem, Middle - See note 1, below
38 Tri Ring, Divert Stem EPDM
106036+ 107693+ 107048+ 111633+ 102492+ 114216+
FKM
107991+ 107984+ 107982+ 111635+ 107978+ 114219+
39 O-ring, Divert stem EPDM
E70210 E70215 E70217 E70217 E70217 E70223
FKM
V70210 V70215 V70217 V70217 V70217 V70223
Notes: * Recommended Spare Parts
PL5027-CH56a
*** See actuator parts lists
1.
4. Unless otherwise noted, quantity required is 1.
6. POA = Part # on availability; N/A = not available with this design.
For items 8, 16, 37, see W73 Divert Mix Proof Seat Lift with External Flush Valve Stems Chart.
*
Stem, Lower Assembly - See note 1, below
Part Description
21a
Contact Factory
***
14a
*
*
*
*
*
*
*
*
Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 69
W73 Divert Mix Proof Seat Lift Valve with External Flush
