5. EPDM recommended on all steam-contact seals.
6. POA = Part # on availability; N/A = not available with this design.
7. Part number includes lower stem and stem bushing, which are assembled together.
8. Part number includes upper stem and coupling sleeve, which are assembled together.
9. Part number includes lower stem and inner stem, which are assembled together.
10. A separate actuator stem (item 24) mates with item 8.
11. Part number includes upper stem, outer stem and coupling sleeve, which are assembled together.
12. Part number includes upper stem, outer stem and outer stem bushing, which are assembled together.
13. Unless otherwise noted, quantity required is 1.
PL5027-CH138
Parts Lists Waukesha Cherry-Burrell
Page 72 95-03087 10/2012
W72RS Mix Proof Seat Lift with Upper Balancer Option (See page 56)
W72RS Mix Proof Seat Lift Tank Outlet (See page 58)
W72RS Mix Proof Seat Lift Tank Outlet with External Flush (See page 60)
W72RSP Valve Stems
W72RSP Mix Proof Seat Lift (See page 62)
W72RSP Mix Proof Seat Lift with External Flush (See page 64)
Item # Part Description 2" 2-1/2" 3" 4"
8 Stem, Upper 126052+ POA 126043+ 126059+
16
Stem, Lower Assembly
9
119437+ 119438+ 119439+ 119440+
PL5027-CH137
Item # Part Description 2-1/2" 3" 4" 6"
8 Stem, Outer (Pipe Side) 126015+ 125970+ 126020+ POA
16 Stem, Inner (Tank Side) 125996+ 125967+ 126024+ POA
PL5027-CH136
Item # Part Description 2-1/2" 3" 4" 6"
8 Stem, Outer (Pipe Side) POA 127748+ 129289+ POA
16 Stem, Inner (Tank Side) POA 127749+ 129381+ POA
24 Stem, Actuator POA 109910+ 116821+ POA
PL5027-CH149
Item # Part Description 2.5" 3" 4" 6"
8 Stem, Upper Assembly
11
126880+ 126880+ 126880+ POA
16
Stem, Lower Assembly
9
129983+ 129983+ 129983+ POA
PL5027-CH158
Item # Part Description 2.5" 3" 4" 6"
8 Stem, Upper Assembly
11
128536+ 128536+ 128536+ POA
16 Stem, Lower Assembly
9
129984+ 129984+ 129984+ POA
24 Stem, Actuator 128535+ 128535+ 128535+ POA
PL5027-CH157
