Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 73
W73 Valve Stems
W73 Divert Mix Proof Seat Lift (See page 66)
W73 Divert Mix Proof Seat Lift with External Flush (See page 68)
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper 111042+ 111014+ 111052+ 111022+ 111049+ POA
16a Stem, Lower 116686+ 115911+ 116388+ 114506+ 115651+ 128650+
37a Stem, Middle, Tri-Ring POA POA POA POA POA POA
PL5027-CH124a
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper Assembly
12
119200+ 119201+ 119202+ 119203+ 119204+ 128647+
16a Stem, Lower 116686+ 115911+ 116388+ 114506+ 115651+ 128650+
16c Stem, Lower Flush POA POA POA POA POA POA
37a Stem, Middle, Tri-Ring POA POA POA POA POA POA
PL5027-CH126a
5. EPDM recommended on all steam-contact seals.
6. POA = Part # on availability; N/A = not available with this design.
7. Part number includes lower stem and stem bushing, which are assembled together.
8. Part number includes upper stem and coupling sleeve, which are assembled together.
9. Part number includes lower stem and inner stem, which are assembled together.
10. A separate actuator stem (item 24) mates with item 8.
11. Part number includes upper stem, outer stem and coupling sleeve, which are assembled together.
12. Part number includes upper stem, outer stem and outer stem bushing, which are assembled together.
13. Unless otherwise noted, quantity required is 1.
PL5027-CH138
