SPX W Series User Manual

Parts Lists Waukesha Cherry-Burrell
Page 70 95-03087 10/2012
W71 Valve Stems
W71 Mix Proof Non-Seat Lift (See page 32)
W71 Mix Proof Non-Seat Lift with External Flush (See page 34)
W71 Mix Proof Non-Seat Lift with Steam Adapter (See page 36)
W71 Mix Proof Seat Lift (See page 38)
W71 Mix Proof Seat Lift with External Flush (See page 40)
W71 Mix Proof Seat Lift with Steam Adapter (See page 42)
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8a Stem, Upper 116615+ 115788+ 115663+ 115648+ 115793+ POA
16a
Stem, Lower Assembly
7
118150+ 118151+ 118152+ 118153+ 118154+ POA
PL5027-CH104a
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8a Stem, Upper Assembly
8, 10
106015+ 106016+ 106017+ 106018+ 106019+ 128647+
16a
Stem, Lower Assembly
9
106051+ 106052+ 106053+ 106054+ 106055+ 129719+
24 Stem, Actuator, NSL Flush 107790+ 107756+ 107949+ 107949+ 107949+ 129703+
PL5027-CH105a
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8a Stem, Upper Assembly
8
130673+ 126218+ POA 122284+ POA POA
16a
Stem, Lower Assembly
9
114933+ 114934+ 114935+ 114936+ 114937+ POA
24 Stem, Actuator, NSL Flush 107790+ 107756+ 107949+ 107949+ 107949+ 129703+
PL5027-CH130a
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8a Stem, Upper 111042+ 111014+ 111052+ 111022+ 111049+ POA
16a
Stem, Lower Assembly
7
118247+ 118248+ 118249+ 118250+ 118251+ POA
PL5027-CH106a
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8a Stem, Upper Assembly
11
119199+ 119200+ 119201+ 119202+ 119203+ POA
16a
Stem, Lower Assembly
9
111499+ 111513+ 111519+ 111520+ 111524+ POA
PL5027-CH107a
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8a Stem, Upper Assembly
11
POA POA POA POA POA N/A
16a
Stem, Lower Assembly
9
118241+ 118409+ 118243+ 118244+ 118245+ N/A
PL5027-CH131a
Notes
5. EPDM recommended on all steam-contact seals.
6. POA = Part # on availability; N/A = not available with this design.
7. Part number includes lower stem and stem bushing, which are assembled together.
8. Part number includes upper stem and coupling sleeve, which are assembled together.
9. Part number includes lower stem and inner stem, which are assembled together.
10. A separate actuator stem (item 24) mates with item 8.
11. Part number includes upper stem, outer stem and coupling sleeve, which are assembled together.
12. Part number includes upper stem, outer stem and outer stem bushing, which are assembled together.
13. Unless otherwise noted, quantity required is 1.
PL5027-CH138
