Notes
5. EPDM recommended on all steam-contact seals.
6. POA = Part # on availability; N/A = not available with this design.
7. Part number includes lower stem and stem bushing, which are assembled together.
8. Part number includes upper stem and coupling sleeve, which are assembled together.
9. Part number includes lower stem and inner stem, which are assembled together.
10. A separate actuator stem (item 24) mates with item 8.
11. Part number includes upper stem, outer stem and coupling sleeve, which are assembled together.
12. Part number includes upper stem, outer stem and outer stem bushing, which are assembled together.
13. Unless otherwise noted, quantity required is 1.
PL5027-CH138
Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 71
W72RS Valve Stems
W72RS Mix Proof Non-Seat Lift (See page 44)
W72RS Mix Proof Non-Seat Lift with External Flush (See page 46)
W72RS Mix Proof Non-Seat Lift with Steam Adapter (See page 48)
W72RS Mix Proof Seat Lift (See page 50)
W72RS Mix Proof Seat Lift with External Flush (See page 52)
W72RS Mix Proof Seat Lift with Steam Adapter (See page 54)
W72RS Valve Stems continued on next page.
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper 119268+ 118484+ 119281+ 118534+ 119346+ POA
16
Stem, Lower Assembly
9
119477+ 119478+ 119479+ 119480+ 119481+ POA
PL5027-CH102
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper Assembly
11
106015+ 106016+ 106017+ 106018+ 106019+ POA
16 Stem, Lower Assembly
9
POA 120893+ 125484+ 120894+ POA POA
24 Stem, Actuator, NSL Flush 122389+ 118642+ 118625+ 118625+ 107949+ 129703+
PL5027-CH108
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper Assembly
7
119452+ 119453+ 119454+ 119455+ 119456+ POA
16 Stem, Lower Assembly
8
119462+ 119463+ 119464+ 119465+ 119466+ POA
24 Stem, Actuator, NSL Flush 122389+ 118642+ 118625+ 118625+ 107949+ 129703+
PL5027-CH132
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper 113390+ 113091+ 113263+ 113102+ 113265+ POA
16
Stem, Lower Assembly
9
119436+ 119437+ 119438+ 119439+ 119440+ POA
PL5027-CH121
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper Assembly
11
119447+ 119448+ 119449+ 119450+ 119451+ POA
16
Stem, Lower Assembly
9
119457+ 119458+ 119459+ 119460+ 119461+ POA
PL5027-CH122
Item # Part Description 1-1/2" 2" 2-1/2" 3" 4" 6"
8 Stem, Upper Assembly
11
119452+ 119453+ 119454+ 119455+ 119456+ POA
16
Stem, Lower Assembly
9
119462+ 119463+ 119464+ 119465+ 119466+ POA
PL5027-CH133
