SPX W Series User Manual

Item #
4" Diameter
1
6" Diameter
1
8" Diameter
1
1 106050+ 107951+ POA
1a Indicator Stem - Control Top 106003+ 106004+ POA
4 Cylinder 106006+ 106007+ 128394+
* 5 Bearing, Indicator Stem
102757+ 102757+ 102757+
* 6 O-ring, Indicator Stem Nitrile
N70210 N70210 N70210
* 7 O-ring, Cylinder Nitrile
N70240 N70255 N70367
* 8 O-ring, Piston Nitrile
N70342 N70433 N70443
9 Cap Screw, 1/4-20 x .375" lg. 30-68 (4 req) 30-68 (8 req) 30-361 (12 req)
10 Piston & Spring Assembly 118461+ 118530+ POA
* 11 O-ring, Yoke Nitrile
N70210 N70214 N70214
12 Yoke 1-1/2" 106119+ -- --
2" 107764+ -- --
2-1/2" -- 106120+ --
3" -- 106121+ --
4" -- 106118+ --
6'' -- -- 128396+
13 Vent Plug (see note 2)
3023957+ 3023957+ 3023957
*
14 Bearing, Piston
101995 102052 100256+
*
15 Bearing, Yoke
102757+ 106047+ 106047+
18 Spring, Upper Stem
101946 5901106 5901106+
31 Washer (see note 3) 43-55 --
32 Spring Guide
118459 118529 POA
33 Elbow swivel 90° 78-157 78-157 78-157
For Valve Size
4" Diameter
1
6" Diameter
1
8" Diameter
1
Air-to-Raise Visual Indicator Stem 1-1/2" ACT00342 -- --
2" ACT00343 -- --
2-1/2" -- ACT00344 --
3" -- ACT00345 --
4" -- ACT00346 --
6" -- -- POA
Control Top Indicator Stem 1-1/2" ACT00352 -- --
2" ACT00353 -- --
2-1/2" -- ACT00354 ACT00354
3" -- ACT00355 ACT00355
4" -- ACT00356 ACT00356
6" -- -- POA
No te s:
PL5027-CH62
* Recommended Spare Parts
1.
2. Only required for valves without control top
3. Item 31 is required on 1-1/2" valves only.
Part Description
Indicator Stem - Visual
Part Description
Complete Actuator Assemblies
4-inch diameter actuator for 1-1/2inch and 2-inch valves, 6-inch diameter actuator for 2-1/2 inch through 4-
inch valves, 8-inch diameter actuator for 6-inch valves.
Waukesha Cherry-Burrell Parts Lists
10/2012 95-03087 Page 81
W72RS Non Seat Lift Actuator
