Pin no. Description STM32 pin Signal

9 USART_TX PA7 USART3_TX

10 INT/I2Cz_SMB PG5/PG6/PD15 INT_EX

11 USART_RX PA5 USART3_RX

12 RESET PB1 GPIO1_EX

13 USART_RTS PD13 USART3_RTS

14 ADC PC3 ADC_EX

15 Not used -

16 PWM PC6 TIM3_PWM

17 GPIO3_EX PF10 GPIO3_EX

18 GPIO2_EX PF8 GPIO2_EX

19 SPIx_NSS PI0/PA15 SPI2_NSS/SPI3_NSS

20 Not used -

21 SPIx_MOSIp PI3/PB5 SPI2_MOSI/SPI3_MOSI

22 GPIO1/SAI1_SCK PE5 SAI1_SCK_A

23 SPIx_MISOp PD3/PB4 SPI2_ MISO/SPI3_MISO

24 GPIO2/SAI1_FS PE4 SAI1_FS_A

25 SPIx_SCK PI1/PG9 SPI2_ SCK/SPI3_SCK

26 GPIO3/SAI1_SD PE3/PE6 SAI1_SD_A/SAI1_SD_B

27 I2Cz_SCL PG7 I2C3_SCL

28 GPIO4/SAI1_MCLK PE2 SAI1_MCLK_A

29 V REG2 - 3V3_Ext

30 SPIx_MISOs PI2 SPI2_MISO_P2

31 VCONN 5V/SYS

32 Not used - -

33 GND - -

34 GND - -
