ST STEVAL-STWINBX1 - Bill of Materials; Table 18. STEVAL-STWINBX1 Bill of Materials; Table 19. Core System Board Bill of Materials

6 Bill of materials
Table 18. STEV
AL-STWINBX1 bill of materials
Item Q.ty Ref. Part/value Description Manufacturer Order code
1 1
Table 19. STEVAL-
STWBXCS1
- Core system board ST Not available for separate sale
2 1 Table 20. STEVAL-C34DIL24 - Adapter board ST Not available for separate sale
3 1 - - Plastic case - -
4 4 - - Screws - -
5 1 - - Programming cable - -
Table 19. Core system board bill of materials
Item Q.ty Ref. Part/value Description Manufacturer Order code
1 1 A1 U.FL connector
Coaxial U.FL
(not mounted)
- -
2 1 BATT1
Battery
connector
Battery
connector
Molex 78171-0003
3 1 CN1
CON34 SMD
gold
Connector
socket
Panasonic
Electric W
orks
AXF5G3412A
4 1 CN3
CON4, 0.50 mm
pitch
4-pin FFC/FPC
connector
Hirose FH33J-4S-0.5SH(10)
5 1 CN4 STDC14
STDC14-ARM
MIPI10
compatible
Samtec FTSH-107-01-L-DV-K-P
6 1 CN5 NU
STDC14- RM
MIPI10
compatible (not
mounted)
Samtec FTSH-107-01-L-DV-K-P
7 1 CS1 CS V3 4L 35um
C.S. (not
mounted)
- -
8 42
C1, C2, C3, C7,
C9, C12, C13,
C14, C15, C22,
C25, C26, C27,
C28, C29, C31,
C32, C33, C35,
C37, C38, C39,
C42, C43, C45,
C48, C49, C51,
C52, C56, C57,
C58, C59, C61,
C62, C64, C65,
C66, C70, C72,
C74, C80
100 nF, 0402
(1005 metric),
0.1 µF
, ±10%,
X7R
Ceramic
capacitors
Murata
Electronics
North America
GRM155R71C104KA88J
9 11
C4, C10, C18,
C20, C50, C53,
C54, C60, C63,
C78, C79
10µF, 10 V,
0402 (1005
metric), ±20%,
X5R
Ceramic
capacitors
Samsung
Electro-
Mechanics
America, Inc.
CL05A106MP8NUB8
11 6
C8, C23, C46,
C76, C77, C83
10 nF, 25 V,
0402 (1005
metric),
±10%,X7R
Ceramic
capacitors
AVX
Corporation
04023C103KAT2A
12 8
C11, C17, C24,
C40, C44, C47,
C67, C75
1 µF, 10 V, 0402
(1005 metric),
±10%, X5R
Ceramic
capacitors
Taiyo Yuden JMK105BJ105KV-F
UM2965
Bill of materials
UM2965 - Rev 1
page 44/58
