Item Q.ty Ref. Part/value Description Manufacturer Order code
13 1 C16
0.22 µF, 16 V,
0402 (1005
metric), ±10%,
X7R
Ceramic
capacitor
Murata
Electronics
North America
GRM155R71C224KA12D
14 4
C19, C55, C86,
C87
47 µF, 10 V,
0603 (1608
metric), ±20%,
X5R
Ceramic
capacitors
Murata
Electronics
North America
ZRB18AR60J476ME01L
15 3 C21, C30, C34
4.7 µF, 10 V,
0402 (1005
metric), ±20%,
X5R
Ceramic
capacitors
Murata
Electronics
North America
GRM155R61A475MEAAD
16 2 C36, C41
6.8 pF, 10 V,
0402 (1005
metric), ±5%,
C0G/NP0
Ceramic
capacitors
Murata
Electronics
North America
GRM0225C1E6R8CA03L
17 4
C68, C69, C71,
C73
2.2 µF, 10 V,
1210 (3225
metric), ±20%,
X5R
Ceramic
capacitors
Wurth
Electronics Inc.
Wurth-885012105013
18 1 C81
100 pF, 10 V,
0402 (1005
metric), ±5%,
C0G/NP0
Ceramic
capacitor
Wurth
Electronics Inc.
'885012005013
19 1 C82
10 n/1 kV, 1206,
±10%, X7R
Ceramic
capacitor
AVX 1206AC103KAT1A
20 1 C84
10000 PF, NU,
0402 (1005
metric), ±10%,
X7R
Ceramic
capacitor (not
mounted)
- -
21 1 C85
330 pF, NU,
0402 (1005
metric), ±10%,
Ceramic
capacitor (not
mounted)
- -
22 1 DS1
BAT30KFILM,
SOD-523
30 V, 300 mA
SMD general-
purpose signal
Schottky diode
ST BAT30KFILM
23 2 D4, D7
DIODE
SCHOTTKY
,
STmite
20 V, 1 A
STmite power
Schottky
rectifier
ST STPS120M
24 1 D6
ESDA7P60-1U1
M, QFN-2L
High-power
transient
voltage
suppressor
ST ESDA7P60-1U1M
25 2 D8, D9
NU, VFQFPN 2
0.6x1
Single-line low
capacitance and
low leakage
current ESD
protection (not
mounted)
ST ESDALCL5-1BM2
26 4
FID1, FID2,
FID3, FID4
TPS
Fiducial (not
mounted)
- -
27 1 J1 NU
Stripline for
RS485 (not
mounted)
- -
28 3 J4, J8, J11 NU
Jumpers (not
mounted)
- -
UM2965
Bill of materials
UM2965 - Rev 1
page 45/58
