6.2 Bill of materials (BOM)
Table 14. STEVAL-WBC2TX50 BOM
Item Qty Ref. Value Package Description Manuf. Part number
1 7
C100,
C203,
C241,
C242,
C243,
C302,
C309
100 nF 0402
CAPACITOR SMD 0402 100nF
50V X7R 10%
Wurth 885012205086
2 18
C101,
C102,
C103,
C300,
C301,
C304,
C305,
C306,
C307,
C317,
C318,
C319,
C401,
C402,
C404,
C405,
C410,
C411
10 µF 1206
CAPACITOR SMD 1206 10uF 50V
X7R 10% Derating
TDK C3216X7R1H106KT0A0E
3 1 C106 33 nF 0603
CAPACITOR SMD 0603 33nF 50V
X7R 10%
Wurth 885012206092
4 2
C201,
C235
4.7 µF 0402
CAPACITOR SMD 0402 4.7UF
6.3V X5R 20%
Wurth 885012105008
5 1 C202 470 nF 0402
CAPACITOR SMD 0402 470nF
35V X5R 20%
KEMET C1005X5R1V474M050BC
6 5
C204,
C206,
C229,
C500,
C504
10 µF 0603
CAPACITOR SMD 0603 10UF 16V
X7R 20%
Wurth 885012106031
7 8
C207,
C215,
C217,
C218,
C223,
C224,
C230,
C236
100 nF 0402
CAPACITOR SMD 0402 100nF
25V X7R 10%
Wurth 885012205085
8 3
C208,
C310,
C505
1 nF 0402
CAPACITOR SMD 0402 1nF 50V
C0G 5%
Wurth 885012005067
9 6
C210,
C400,
C403,
C432,
C433,
C502
100 nF 0603
CAPACITOR SMD 0603 100nF
50V X7R 10%
Wurth 885012206095
10 3
C211,
C212,
C213
330 nF 0603
CAPACITOR SMD 0603 330nF
50V X7R 10%
Wurth 885012206121
11 6
C214,
C216,
C225,
C227,
C314,
C315
10 nF 0402
CAPACITOR SMD 0402 10nF 50V
X7R 10%
Wurth 885012205067
