Item Qty Ref. Value Package Description Manuf. Part number
12 1 C220 1 nF 0402
CAPACITOR SMD 0402 1nF 100V
X7R 10%
Wurth 885012205080
13 2
C221,
C222
N.A. 0402 Not populated capacitor SMD 0402 N.A. N.A.
14 1 C228 33 pF 0402
CAPACITOR SMD 0402 33pF 50V
C0G 5%
Wurth 885012005058
15 1 C238 1 µF 0402
CAPACITOR SMD 0402 1UF 6.3V
X5R 10%
MURATA GRT155R60J105KE01D
16 1 C240 2.2 nF 0402
CAPACITOR SMD 0402 2.2nF 50V
X7R 5%
MURATA GCM155R71H222JA37D
17 2
C303,
C308
100 µF
CAPP_D6.3_PANA_
D8
100uF Aluminum Electrolytic
Capacitors High temperature Lead-
Free reflow
PANASONIC EEEFTH101XAP
18 1 C313 22 nF 0402
CAPACITOR SMD 0402 22nF
50V X7R 10%
Murata GRM155R71H223KA12D
19 2
C407,
C408
100 nF 1812
CAPACITOR SMD 1812 100nF
100V C0G 5%
TDK C4532C0G2A104J320KA
20 1 C409 47 nF 1812
CAPACITOR SMD 1812 47nF
100V C0G 5%
TDK C4532C0G2A473J200KA
21 1 C412 5.6 nF 0402
CAPACITOR SMD 0402 5.6nF 50V
X7R 10%
KEMET C0402C562K5RACTU
22 1 C415 5.6 nF 1206
CAPACITOR SMD 1206 5.6nF
100V X7R 10%
KEMET C1206X562K1RACTU
23 1 C503 220 pF 0402
CAPACITOR SMD 0402 220pnF
50V X7R 10%
Wurth 885012205057
24 1 C506 82 nF 0402
CAPACITOR SMD 0402 82nF 16V
X7R 10%
YAGEO CC0402KRX7R7BB823
25 1 C507 8.2 nF 0402
CAPACITOR SMD 0402 8.2nF 50V
X7R 10%
KEMET C0402C822K5RAC7867
26 1 C508 10 nF 0402
CAPACITOR SMD 0402 10nF 16V
X7R 10%
Wurth 885012205031
27 1 D100 SMM4F24A SMB 400 W, 24 V TVS in STmite Flat ST SMM4F24A-TR
28 1 D102 ECMF02-2AMX6 DIOD_UQFN-6L
COMMON MODE FILTER WITH
ESD PROTECTION
ST ECMF02-2AMX6
29 1 D103 ESDALC6V1M3 SOT883
VERY LOW CAPACITANCE LOW
LEAKAGE CURRENT ESD
PROTECTION
ST ESDALC6V1M3
30 2
D200,
D201
RB541VM-40 SOD323
SMT Schottky Diode, 40V 200mA,
2-Pin SOD-323
Rohm RB541VM-40TE-17
31 1 D202 RED 0603 LED, 0603, Red
WURTH
ELEKTRONIK
150060RS75000
32 1 D203 GREEN 0603 LED, 0603, Green
WURTH
ELEKTRONIK
150060VS75000
33 3
D204,
D205,
D206
BAT54KFILM SOD523 SMALL SIGNAL_40V_300mA ST BAT54KFILM
34 1 D400 10 V SOD323 VOLTAGE_REGULATOR_0.3W NXP OR OTHERS BZX384-C10,115
35 1 D500 5 V SOD882 TRANSIL ESD 5V UNI LRC LESD8D5.0AT5G
36 1 D501 LMBR240ET1G SOD323
SMT Schottky Diode, 40V 2A, 2-Pin
SOD-323
LRC LMBR240ET1G
37 1 F500 Fan Port
Fan Port, 4 PIN 1mm pitch wire to
board connector
HDGC HDGC1002WR-S-4P
38 1 J100 632723300011
CON_USB_C_6327
23300011
USB TYPE C_632723300011
WURTH
ELEKTRONIK
632723300011
UM3231
