ST STEVAL-WBC2TX50 - Page 51

Item Qty Ref. Value Package Description Manuf. Part number
39 1 J101 POWER JACK DC
CON_JACK_21MM-
PJ-002A
POWER JACK DC
WURTH
ELEKTRONIK
694106301002
40 1 J201 4-pin 1X4P_2.54mm Header, 1X4P, 2.54mm Harwin M20-9770446
41 1 J203
FTSH-107-01-L-DV-
K-A
CON_FTSH-107-01-
L-DV-K-A
SMD_HEADER_2x7_P1.27 SAMTEC FTSH-107-01-L-DV-K-A
42 2
L200,
L500
10 µH L2.5_W2.0_H1.2 ISAT 1.3A / DCR max 0.540 Ohm TDK VLS252012HBX-100M-1
43 1 L300 3.3 µH L17.3_W16.5
3.3uH, 30.9A, 0.0022Ohm, 10%,
L17.3XW16.6
TDK B82559B5332A016
44 1 L400 1 µH L9.2_W8.5 ISAT14A - RDC=0.0046mohm max
WURTH
ELEKTRONIK
74437358010
45 1 Q201 N-MOS SOT23 Enhancement Mode Field Effect ONSEMI 2N7002
46
6
Q300,
Q301,
Q400,
Q401,
Q402,
Q403
STL20N6F7 PowerFLAT_3.3x3.3
60V_0.0054R_20A_N-Channel
AlphaSGT
ST STL20N6F7
47 1 Q500 LMBT2222AWT1G SC323 NPN, 40V 600mA LRC LMBT2222AWT1G
48 1 Q404 STL42P6LLF6 POWERFLAT_5X6 60V_0.023R_42A_P-Channel ST STL42P6LLF6
49 1 Q405 PDTC114EU,135 SOT323
GENERAL
PURPOSE_50V_100mA_205mW
RB=RC=10K
NXP PDTC114EU,135
50 1 Q406 STL6N3LLH6 PowerFLAT_2x2 30V_0.021R_6A_N-Channel ST STL6N3LLH6
51
6
R101,
R102,
R201,
R219,
R306,
R307
10 R 0402
RESISTOR SMD 10
R_5%_0402_1/16W
YAGEO RC0402JR-0710RL
52
14
R106,
R107,
R220,
R236,
R237,
R301,
R302,
R400,
R403,
R404,
R405,
R407,
R416,
R417
0 R 0402
RESISTOR SMD
0R_5%_0402_1/16W
YAGEO RC0402JR-070RL
53 1 R200 0.1 R 0402
RESISTOR SMD 0.1
R_5%_0402_1/16W
YAGEO RL0402JR-070R1L
54
14
R202,
R204,
R208,
R209,
R229,
R303,
R304,
R412,
R413,
R414,
R415,
R505,
R507,
R509
10 K 0402
RESISTOR SMD 10
K_5%_0402_1/16W
YAGEO RC0402JR-0710KL
55 2
R203,
R210
150 K 0402
RESISTOR SMD 150
K_5%_0402_1/16W
YAGEO RC0402JR-07150KL
UM3231
