ST STEVAL-WBC2TX50 - Page 52

Item Qty Ref. Value Package Description Manuf. Part number
56 2
R206,
R211
47 K 0402 NTC SMD 0402 47k 1% MURATA NCP15WB473F03RC
57 1 R207 100 K 0402
RESISTOR SMD 100
K_1%_0402_1/16W
YAGEO RC0402FR-07100KL
58 3
R212,
R225,
R226
2.2 R 0402
RESISTOR SMD 2.2
R_5%_0402_1/16W
YAGEO RC0402JR-072R2L
59 2
R213,
R217
470 K 0402
RESISTOR SMD 470
K_5%_0402_1/16W
YAGEO RC0402JR-07470KL
60 1 R218 3.3 K 0402
RESISTOR SMD 3.3
K_1%_0402_1/16W
YAGEO RC0402FR-073K3L
61 2
R227,
R228
4.7 K 0402
RESISTOR SMD 4.7
K_5%_0402_1/16W
YAGEO RC0402JR-074K7L
62 2
R230,
R234
180 K 0402
RESISTOR SMD 180
K_0.1%_0402_1/16W
YAGEO RE0402BRE07180KL
63 1 R231 1.2 K 0402
RESISTOR SMD 1.2
K_0.1%_0402_1/16W
YAGEO RE0402BRE071K2L
64 1 R232 9.1 K 0402
RESISTOR SMD 9.1
K_0.1%_0402_1/16W
YAGEO RE0402BRE079K1L
65 1 R233 5.6 K 0402
RESISTOR SMD 5.6
K_0.1%_0402_1/16W
YAGEO RE0402BRE075K6L
66 1 R235 100 R 0402
RESISTOR SMD 100
R_5%_0402_1/16W
YAGEO RC0402JR-07100RL
67 1 R300
0.010 R
2W
2512
RESISTOR SMD 0.010
R_1%_2512_2W
Wurth 580070763010
68 1 R305 3.3 R 1206
RESISTOR SMD 3.3
R_5%_1206_1/4W
YAGEO RC1206JR-073R3L
69 1 R408
0.010 R
0.1%
1W
2512
RESISTOR SMD 0.010
R_0.1%_2512_1W
Vishay Precision
Group Foil
Resistors
Y14870R01000B9R
70 2
R410,
R411
30 K 0402
RESISTOR SMD 30
K_5%_0402_1/16W
YAGEO RC0402JR-0730KL
71 1 R500 576 R 0402
RESISTOR SMD 576
R_1%_0402_1/16W
YAGEO RC0402FR-07576RL
72 1 R501 38.3 K 0402
RESISTOR SMD 38.3
K_1%_0402_1/16W
YAGEO RC0402FR-0738K3L
73 1 R502 510 R 0402
RESISTOR SMD 510
R_1%_0402_1/16W
YAGEO RC0402FR-07510RL
74 1 R503 160 R 0402
RESISTOR SMD 160
R_1%_0402_1/16W
YAGEO RC0402FR-07160RL
75 1 R504 4.7 K 0402
RESISTOR SMD 4.7
K_1%_0402_1/16W
YAGEO RC0402FR-074K7L
76 1 R506 47 K 0402
RESISTOR SMD 47
K_5%_0402_1/16W
YAGEO RC0402JR-0747KL
77 1 R508 1 K 0402
RESISTOR SMD 1
K_5%_0402_1/16W
YAGEO RC0402JR-071KL
78 1 R510 0 R 0805
RESISTOR SMD 0
R_5%_0805_1/8W
UNI-ROYAL 0805W8J0000T5E
79 1 U200 STWBC2
VFQFPN68L_L8_W
8_P0.4
FOR WIRELESS BATTERY
CHARGER TRANSMITTERS Qi
ST STWBC2
80 1 U201 STSAFE-A110 UFDFPN8
AUTHENTIFICATION, BRAND
PROTECTION SECURE
SOLUTION
ST STSAFE-A110
81 1 U203 LMV321ILT SOT23-5L Rail-to-rail operational amplifier ST LMV321ILT
UM3231
STEVAL-WBC2TX50 description
UM3231 - Rev 1
page 52/84
